| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A03_030T01_9000001194_08473cztM0_level2.evt | modeM0/AS1A03_030T01_9000001194_08473cztM0_level2_quad_clean.evt |
| Size (bytes) | 615,386,880 | 78,583,680 |
| Size | 586.9 MB | 74.9 MB |
| Events in quadrant A | 3,646,890 | 485,713 |
| Events in quadrant B | 3,732,776 | 488,205 |
| Events in quadrant C | 3,595,359 | 477,852 |
| Events in quadrant D | 7,148,395 | 400,847 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 152 | 0 |
| B | 0 | 152 | 0 |
| C | 0 | 152 | 0 |
| D | 0 | 152 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15981 | 2 |
| B | 0 | 16068 | 1 |
| C | 0 | 15904 | 1 |
| D | 0 | 26363 | 1 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 3 | 0 |
| B | 0 | 3 | 0 |
| C | 0 | 3 | 0 |
| D | 0 | 3 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7569 | 371 | 4.901572% |
| B | 7569 | 371 | 4.901572% |
| C | 7569 | 248 | 3.276523% |
| D | 7569 | 1470 | 19.421324% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7799 | 7569 | 1 | 1 | 0.01% | 0.01% |  |
| B | 7799 | 7569 | 4 | 4 | 0.05% | 0.05% |  |
| C | 7799 | 7569 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7798 | 7569 | 1135 | 1135 | 14.56% | 15.00% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 248 | 18647 | 91.27 | 937 | 914 | 194.3 |
| A | 4 | 2 | 10857 | 51.18 | 937 | 914 | 194.3 |
| A | 13 | 251 | 10346 | 48.55 | 937 | 914 | 194.3 |
| B | 11 | 51 | 31764 | 168.42 | 936 | 910 | 183.2 |
| B | 0 | 214 | 28356 | 149.82 | 936 | 910 | 183.2 |
| B | 12 | 111 | 21237 | 110.96 | 936 | 910 | 183.2 |
| C | 8 | 128 | 16927 | 74.55 | 913 | 915 | 214.8 |
| C | 8 | 112 | 7613 | 31.19 | 913 | 915 | 214.8 |
| C | 13 | 61 | 6919 | 27.95 | 913 | 915 | 214.8 |
| D | 13 | 105 | 3512923 | 17092.96 | 852 | 826 | 205.5 |
| D | 1 | 52 | 96514 | 465.7 | 852 | 826 | 205.5 |
| D | 12 | 221 | 76561 | 368.59 | 852 | 826 | 205.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
