| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G07_007T01_9000001196_08487cztM0_level2.evt | modeM0/AS1G07_007T01_9000001196_08487cztM0_level2_quad_clean.evt |
| Size (bytes) | 601,752,960 | 96,975,360 |
| Size | 573.9 MB | 92.5 MB |
| Events in quadrant A | 6,308,194 | 579,087 |
| Events in quadrant B | 3,988,739 | 623,895 |
| Events in quadrant C | 3,451,187 | 618,696 |
| Events in quadrant D | 3,965,952 | 591,665 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 152 | 0 |
| B | 0 | 152 | 0 |
| C | 0 | 152 | 0 |
| D | 0 | 152 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 1 | 0 |
| B | 0 | 1 | 0 |
| C | 0 | 1 | 0 |
| D | 0 | 1 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 23894 | 2 |
| B | 0 | 16688 | 1 |
| C | 0 | 15623 | 1 |
| D | 0 | 17056 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7518 | 1097 | 14.591647% |
| B | 7518 | 239 | 3.179037% |
| C | 7518 | 138 | 1.835595% |
| D | 7518 | 202 | 2.686885% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7613 | 7520 | 783 | 783 | 10.29% | 10.41% |  |
| B | 7613 | 7520 | 13 | 13 | 0.17% | 0.17% |  |
| C | 7613 | 7520 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7613 | 7520 | 31 | 31 | 0.41% | 0.41% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 5 | 16 | 2924115 | 16279.91 | 869 | 849 | 179.6 |
| A | 15 | 236 | 24435 | 131.35 | 869 | 849 | 179.6 |
| A | 13 | 251 | 13874 | 72.54 | 869 | 849 | 179.6 |
| B | 0 | 214 | 201573 | 1134.13 | 910 | 888 | 177.0 |
| B | 11 | 51 | 105980 | 593.91 | 910 | 888 | 177.0 |
| B | 4 | 80 | 49140 | 272.69 | 910 | 888 | 177.0 |
| C | 13 | 61 | 6745 | 28.17 | 884 | 889 | 207.9 |
| C | 8 | 222 | 5143 | 20.46 | 884 | 889 | 207.9 |
| C | 3 | 202 | 2230 | 6.45 | 884 | 889 | 207.9 |
| D | 12 | 233 | 260689 | 1175.39 | 889 | 862 | 221.1 |
| D | 1 | 52 | 151909 | 683.3 | 889 | 862 | 221.1 |
| D | 10 | 119 | 71092 | 317.7 | 889 | 862 | 221.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
