| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G07_060T01_9000001200_08537cztM0_level2.evt | modeM0/AS1G07_060T01_9000001200_08537cztM0_level2_quad_clean.evt |
| Size (bytes) | 425,672,640 | 87,085,440 |
| Size | 406.0 MB | 83.1 MB |
| Events in quadrant A | 2,997,232 | 552,354 |
| Events in quadrant B | 3,486,407 | 553,305 |
| Events in quadrant C | 2,902,874 | 552,662 |
| Events in quadrant D | 3,071,830 | 534,564 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 130 | 0 |
| B | 0 | 130 | 0 |
| C | 0 | 130 | 0 |
| D | 0 | 130 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13268 | 3 |
| B | 0 | 14609 | 2 |
| C | 0 | 13174 | 2 |
| D | 0 | 13759 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 23 | 0 |
| B | 0 | 23 | 0 |
| C | 0 | 23 | 0 |
| D | 0 | 23 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6370 | 51 | 0.800628% |
| B | 6370 | 174 | 2.731554% |
| C | 6370 | 36 | 0.565149% |
| D | 6370 | 55 | 0.863422% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 8580 | 6372 | 4 | 4 | 0.05% | 0.06% |  |
| B | 8580 | 6371 | 92 | 92 | 1.07% | 1.44% |  |
| C | 8580 | 6372 | 1 | 1 | 0.01% | 0.02% |  |
| D | 8580 | 6372 | 10 | 10 | 0.12% | 0.16% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 251 | 79262 | 510.27 | 753 | 735 | 153.9 |
| A | 5 | 16 | 12926 | 79.22 | 753 | 735 | 153.9 |
| A | 8 | 5 | 8396 | 49.78 | 753 | 735 | 153.9 |
| B | 10 | 16 | 464646 | 3250.3 | 752 | 735 | 142.7 |
| B | 10 | 252 | 28170 | 192.22 | 752 | 735 | 142.7 |
| B | 0 | 214 | 26595 | 181.18 | 752 | 735 | 142.7 |
| C | 14 | 234 | 10209 | 55.03 | 741 | 747 | 171.9 |
| C | 13 | 61 | 5566 | 28.03 | 741 | 747 | 171.9 |
| C | 8 | 222 | 3753 | 17.48 | 741 | 747 | 171.9 |
| D | 14 | 34 | 126813 | 711.79 | 732 | 714 | 177.2 |
| D | 1 | 52 | 112138 | 628.96 | 732 | 714 | 177.2 |
| D | 2 | 234 | 20532 | 111.87 | 732 | 714 | 177.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
