| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G07_024T01_9000001206_08621cztM0_level2.evt | modeM0/AS1G07_024T01_9000001206_08621cztM0_level2_quad_clean.evt |
| Size (bytes) | 406,941,120 | 115,067,520 |
| Size | 388.1 MB | 109.7 MB |
| Events in quadrant A | 2,839,582 | 760,848 |
| Events in quadrant B | 3,149,326 | 779,366 |
| Events in quadrant C | 2,814,963 | 762,820 |
| Events in quadrant D | 3,084,574 | 735,391 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13030 | 4 |
| B | 0 | 13624 | 1 |
| C | 0 | 13029 | 1 |
| D | 0 | 13817 | 1 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 10 | 0 |
| B | 0 | 10 | 0 |
| C | 0 | 10 | 0 |
| D | 0 | 10 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 128 | 0 |
| B | 0 | 128 | 0 |
| C | 0 | 128 | 0 |
| D | 0 | 128 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6408 | 53 | 0.827091% |
| B | 6409 | 50 | 0.780153% |
| C | 6409 | 56 | 0.873771% |
| D | 6409 | 97 | 1.513497% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7339 | 6409 | 3 | 3 | 0.04% | 0.05% |  |
| B | 7339 | 6409 | 1 | 1 | 0.01% | 0.02% |  |
| C | 7339 | 6409 | 3 | 3 | 0.04% | 0.05% |  |
| D | 7339 | 6409 | 43 | 43 | 0.59% | 0.67% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 174 | 12565 | 80.07 | 728 | 711 | 148.0 |
| A | 8 | 5 | 11714 | 74.32 | 728 | 711 | 148.0 |
| A | 5 | 16 | 10611 | 66.87 | 728 | 711 | 148.0 |
| B | 0 | 219 | 110760 | 791.47 | 734 | 717 | 139.0 |
| B | 0 | 187 | 46455 | 328.96 | 734 | 717 | 139.0 |
| B | 0 | 213 | 31093 | 218.47 | 734 | 717 | 139.0 |
| C | 1 | 3 | 15771 | 91.82 | 711 | 713 | 164.0 |
| C | 14 | 64 | 8022 | 44.57 | 711 | 713 | 164.0 |
| C | 14 | 67 | 6986 | 38.25 | 711 | 713 | 164.0 |
| D | 10 | 253 | 113139 | 590.47 | 705 | 690 | 190.4 |
| D | 13 | 105 | 68393 | 355.51 | 705 | 690 | 190.4 |
| D | 7 | 71 | 51608 | 267.37 | 705 | 690 | 190.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
