| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G07_024T01_9000001206_08626cztM0_level2.evt | modeM0/AS1G07_024T01_9000001206_08626cztM0_level2_quad_clean.evt |
| Size (bytes) | 428,019,840 | 124,015,680 |
| Size | 408.2 MB | 118.3 MB |
| Events in quadrant A | 2,882,332 | 817,707 |
| Events in quadrant B | 3,030,125 | 862,036 |
| Events in quadrant C | 3,001,774 | 849,260 |
| Events in quadrant D | 3,617,211 | 784,851 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13076 | 3 |
| B | 0 | 13311 | 2 |
| C | 0 | 13404 | 2 |
| D | 0 | 15272 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14 | 0 |
| B | 0 | 14 | 0 |
| C | 0 | 14 | 0 |
| D | 0 | 15 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 130 | 0 |
| B | 0 | 130 | 0 |
| C | 0 | 130 | 0 |
| D | 0 | 130 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6334 | 32 | 0.505210% |
| B | 6334 | 32 | 0.505210% |
| C | 6334 | 28 | 0.442059% |
| D | 6334 | 202 | 3.189138% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7639 | 6335 | 15 | 15 | 0.20% | 0.24% |  |
| B | 7639 | 6335 | 1 | 1 | 0.01% | 0.02% |  |
| C | 7639 | 6335 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7639 | 6335 | 169 | 169 | 2.21% | 2.67% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 174 | 43525 | 291.64 | 732 | 716 | 146.8 |
| A | 13 | 248 | 11130 | 70.95 | 732 | 716 | 146.8 |
| A | 0 | 226 | 6887 | 42.04 | 732 | 716 | 146.8 |
| B | 0 | 219 | 28684 | 200.23 | 756 | 740 | 139.6 |
| B | 10 | 246 | 19702 | 135.87 | 756 | 740 | 139.6 |
| B | 0 | 214 | 13659 | 92.57 | 756 | 740 | 139.6 |
| C | 8 | 208 | 121932 | 718.09 | 735 | 739 | 168.8 |
| C | 13 | 61 | 5566 | 28.6 | 735 | 739 | 168.8 |
| C | 14 | 67 | 5320 | 27.14 | 735 | 739 | 168.8 |
| D | 10 | 253 | 371553 | 2145.21 | 713 | 691 | 172.9 |
| D | 12 | 221 | 150901 | 868.87 | 713 | 691 | 172.9 |
| D | 1 | 52 | 146350 | 842.55 | 713 | 691 | 172.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
