| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G07_024T01_9000001206_08632cztM0_level2.evt | modeM0/AS1G07_024T01_9000001206_08632cztM0_level2_quad_clean.evt |
| Size (bytes) | 436,763,520 | 123,246,720 |
| Size | 416.5 MB | 117.5 MB |
| Events in quadrant A | 3,092,788 | 810,375 |
| Events in quadrant B | 3,385,305 | 837,254 |
| Events in quadrant C | 3,084,157 | 815,212 |
| Events in quadrant D | 3,183,709 | 777,321 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14786 | 321 |
| B | 0 | 15094 | 307 |
| C | 0 | 14762 | 335 |
| D | 0 | 15216 | 395 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 3 | 0 |
| B | 0 | 3 | 0 |
| C | 0 | 3 | 0 |
| D | 0 | 3 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 148 | 0 |
| B | 0 | 148 | 0 |
| C | 0 | 148 | 2 |
| D | 0 | 148 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7064 | 113 | 1.599660% |
| B | 7072 | 78 | 1.102941% |
| C | 7054 | 44 | 0.623760% |
| D | 7040 | 87 | 1.235795% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7548 | 7135 | 9 | 9 | 0.12% | 0.13% |  |
| B | 7548 | 7145 | 1 | 1 | 0.01% | 0.01% |  |
| C | 7548 | 7131 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7548 | 7123 | 19 | 19 | 0.25% | 0.27% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 174 | 34934 | 207.63 | 790 | 772 | 164.5 |
| A | 5 | 16 | 20956 | 122.67 | 790 | 772 | 164.5 |
| A | 0 | 226 | 7413 | 40.36 | 790 | 772 | 164.5 |
| B | 0 | 214 | 126061 | 811.29 | 802 | 781 | 154.4 |
| B | 11 | 51 | 66792 | 427.48 | 802 | 781 | 154.4 |
| B | 14 | 1 | 19552 | 121.56 | 802 | 781 | 154.4 |
| C | 8 | 208 | 59920 | 333.59 | 767 | 768 | 177.3 |
| C | 8 | 128 | 9016 | 46.52 | 767 | 768 | 177.3 |
| C | 14 | 67 | 8897 | 45.84 | 767 | 768 | 177.3 |
| D | 13 | 29 | 79360 | 423.71 | 763 | 738 | 185.6 |
| D | 12 | 221 | 59871 | 318.68 | 763 | 738 | 185.6 |
| D | 1 | 52 | 29586 | 155.47 | 763 | 738 | 185.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
