| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G07_024T01_9000001206_08643cztM0_level2.evt | modeM0/AS1G07_024T01_9000001206_08643cztM0_level2_quad_clean.evt |
| Size (bytes) | 454,559,040 | 125,164,800 |
| Size | 433.5 MB | 119.4 MB |
| Events in quadrant A | 3,013,926 | 824,212 |
| Events in quadrant B | 3,548,669 | 843,131 |
| Events in quadrant C | 3,338,655 | 838,520 |
| Events in quadrant D | 3,392,596 | 800,963 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14167 | 3 |
| B | 0 | 15286 | 2 |
| C | 0 | 15022 | 2 |
| D | 0 | 15574 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 17 | 0 |
| B | 0 | 17 | 0 |
| C | 0 | 17 | 0 |
| D | 0 | 18 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 142 | 0 |
| B | 0 | 142 | 0 |
| C | 0 | 142 | 0 |
| D | 0 | 142 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6947 | 28 | 0.403052% |
| B | 6947 | 93 | 1.338707% |
| C | 6947 | 75 | 1.079603% |
| D | 6947 | 71 | 1.022024% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7892 | 6948 | 7 | 7 | 0.09% | 0.10% |  |
| B | 7892 | 6948 | 62 | 62 | 0.79% | 0.89% |  |
| C | 7892 | 6948 | 45 | 45 | 0.57% | 0.65% |  |
| D | 7892 | 6948 | 39 | 39 | 0.49% | 0.56% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 174 | 28938 | 180.95 | 767 | 749 | 155.8 |
| A | 8 | 5 | 12527 | 75.6 | 767 | 749 | 155.8 |
| A | 3 | 1 | 11442 | 68.64 | 767 | 749 | 155.8 |
| B | 0 | 228 | 234445 | 1595.5 | 779 | 760 | 146.5 |
| B | 0 | 219 | 171974 | 1168.98 | 779 | 760 | 146.5 |
| B | 0 | 214 | 46396 | 311.58 | 779 | 760 | 146.5 |
| C | 4 | 254 | 383129 | 2202.48 | 755 | 758 | 173.6 |
| C | 14 | 67 | 7806 | 40.6 | 755 | 758 | 173.6 |
| C | 13 | 61 | 5945 | 29.88 | 755 | 758 | 173.6 |
| D | 7 | 71 | 315222 | 1743.66 | 746 | 726 | 180.4 |
| D | 12 | 233 | 65050 | 356.63 | 746 | 726 | 180.4 |
| D | 2 | 14 | 34346 | 186.4 | 746 | 726 | 180.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
