| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A02_132T01_9000001212_08714cztM0_level2.evt | modeM0/AS1A02_132T01_9000001212_08714cztM0_level2_quad_clean.evt |
| Size (bytes) | 499,510,080 | 104,137,920 |
| Size | 476.4 MB | 99.3 MB |
| Events in quadrant A | 3,597,881 | 658,912 |
| Events in quadrant B | 3,702,890 | 687,580 |
| Events in quadrant C | 3,469,467 | 680,790 |
| Events in quadrant D | 3,880,837 | 637,580 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15254 | 3 |
| B | 0 | 15498 | 2 |
| C | 0 | 14769 | 2 |
| D | 0 | 16263 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 26 | 0 |
| B | 0 | 26 | 0 |
| C | 0 | 26 | 0 |
| D | 0 | 26 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 146 | 0 |
| B | 0 | 146 | 0 |
| C | 0 | 146 | 0 |
| D | 0 | 146 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7015 | 83 | 1.183179% |
| B | 7015 | 90 | 1.282965% |
| C | 7015 | 37 | 0.527441% |
| D | 7015 | 153 | 2.181041% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 9655 | 7016 | 35 | 35 | 0.36% | 0.50% |  |
| B | 9655 | 7017 | 14 | 14 | 0.15% | 0.20% |  |
| C | 9655 | 7017 | 4 | 4 | 0.04% | 0.06% |  |
| D | 9655 | 7017 | 130 | 130 | 1.35% | 1.85% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 251 | 83800 | 460.66 | 884 | 866 | 180.0 |
| A | 5 | 16 | 53432 | 291.98 | 884 | 866 | 180.0 |
| A | 15 | 174 | 46649 | 254.3 | 884 | 866 | 180.0 |
| B | 5 | 255 | 157618 | 919.0 | 899 | 879 | 170.6 |
| B | 10 | 246 | 22511 | 126.83 | 899 | 879 | 170.6 |
| B | 12 | 111 | 17875 | 99.65 | 899 | 879 | 170.6 |
| C | 14 | 234 | 35206 | 168.53 | 879 | 886 | 203.6 |
| C | 12 | 4 | 8232 | 36.07 | 879 | 886 | 203.6 |
| C | 13 | 61 | 6557 | 27.85 | 879 | 886 | 203.6 |
| D | 1 | 52 | 383609 | 1858.26 | 859 | 841 | 206.0 |
| D | 2 | 152 | 82678 | 397.3 | 859 | 841 | 206.0 |
| D | 9 | 64 | 56099 | 268.27 | 859 | 841 | 206.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
