| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A02_132T01_9000001212_08721cztM0_level2.evt | modeM0/AS1A02_132T01_9000001212_08721cztM0_level2_quad_clean.evt |
| Size (bytes) | 725,875,200 | 125,593,920 |
| Size | 692.2 MB | 119.8 MB |
| Events in quadrant A | 5,006,005 | 762,073 |
| Events in quadrant B | 4,952,112 | 786,143 |
| Events in quadrant C | 4,819,168 | 779,912 |
| Events in quadrant D | 6,470,023 | 723,966 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 22192 | 4 |
| B | 0 | 22004 | 9 |
| C | 0 | 22007 | 1 |
| D | 0 | 26692 | 21 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 4 | 0 |
| B | 0 | 4 | 0 |
| C | 0 | 4 | 0 |
| D | 0 | 4 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 218 | 0 |
| B | 0 | 218 | 0 |
| C | 0 | 218 | 0 |
| D | 0 | 218 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 10855 | 104 | 0.958084% |
| B | 10852 | 99 | 0.912274% |
| C | 10856 | 79 | 0.727708% |
| D | 10853 | 561 | 5.169078% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 11181 | 10856 | 10 | 10 | 0.09% | 0.09% |  |
| B | 11181 | 10856 | 0 | 0 | 0.00% | 0.00% |  |
| C | 11181 | 10856 | 2 | 2 | 0.02% | 0.02% |  |
| D | 11181 | 10855 | 471 | 471 | 4.21% | 4.34% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 251 | 174320 | 683.0 | 1244 | 1214 | 253.4 |
| A | 15 | 174 | 36679 | 139.93 | 1244 | 1214 | 253.4 |
| A | 0 | 226 | 11545 | 40.76 | 1244 | 1214 | 253.4 |
| B | 12 | 111 | 26317 | 103.13 | 1256 | 1222 | 243.3 |
| B | 5 | 255 | 25620 | 100.26 | 1256 | 1222 | 243.3 |
| B | 0 | 198 | 22507 | 87.47 | 1256 | 1222 | 243.3 |
| C | 14 | 234 | 25726 | 86.25 | 1225 | 1231 | 284.0 |
| C | 13 | 61 | 9105 | 27.73 | 1225 | 1231 | 284.0 |
| C | 8 | 222 | 7533 | 22.19 | 1225 | 1231 | 284.0 |
| D | 1 | 52 | 1521890 | 5259.23 | 1196 | 1169 | 289.2 |
| D | 2 | 152 | 97899 | 334.53 | 1196 | 1169 | 289.2 |
| D | 8 | 195 | 96567 | 329.92 | 1196 | 1169 | 289.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
