| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G07_010T01_9000001220_08777cztM0_level2.evt | modeM0/AS1G07_010T01_9000001220_08777cztM0_level2_quad_clean.evt |
| Size (bytes) | 593,631,360 | 94,152,960 |
| Size | 566.1 MB | 89.8 MB |
| Events in quadrant A | 3,955,449 | 582,899 |
| Events in quadrant B | 3,840,214 | 589,095 |
| Events in quadrant C | 4,139,657 | 576,210 |
| Events in quadrant D | 5,503,857 | 550,036 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 162 | 0 |
| B | 0 | 162 | 0 |
| C | 0 | 162 | 0 |
| D | 0 | 162 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16955 | 4 |
| B | 0 | 16859 | 3 |
| C | 0 | 17853 | 3 |
| D | 0 | 22011 | 3 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 5 | 0 |
| B | 0 | 5 | 0 |
| C | 0 | 5 | 0 |
| D | 0 | 5 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7952 | 139 | 1.747988% |
| B | 7952 | 203 | 2.552817% |
| C | 7952 | 261 | 3.282193% |
| D | 7952 | 246 | 3.093561% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 8427 | 7953 | 3 | 3 | 0.04% | 0.04% |  |
| B | 8427 | 7953 | 7 | 7 | 0.08% | 0.09% |  |
| C | 8427 | 7954 | 171 | 171 | 2.03% | 2.15% |  |
| D | 8427 | 7953 | 75 | 75 | 0.89% | 0.94% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 8 | 5 | 211671 | 1089.19 | 940 | 915 | 193.5 |
| A | 13 | 251 | 103710 | 531.25 | 940 | 915 | 193.5 |
| A | 3 | 1 | 9482 | 44.27 | 940 | 915 | 193.5 |
| B | 10 | 16 | 116278 | 624.36 | 946 | 921 | 184.8 |
| B | 4 | 173 | 36250 | 191.21 | 946 | 921 | 184.8 |
| B | 12 | 111 | 21347 | 110.55 | 946 | 921 | 184.8 |
| C | 9 | 68 | 556300 | 2600.13 | 916 | 920 | 213.6 |
| C | 13 | 61 | 6951 | 28.24 | 916 | 920 | 213.6 |
| C | 14 | 67 | 5020 | 19.2 | 916 | 920 | 213.6 |
| D | 2 | 16 | 1485063 | 6769.54 | 901 | 879 | 219.2 |
| D | 2 | 152 | 271270 | 1233.29 | 901 | 879 | 219.2 |
| D | 13 | 169 | 100958 | 456.47 | 901 | 879 | 219.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
