| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G07_010T02_9000001222_08786cztM0_level2.evt | modeM0/AS1G07_010T02_9000001222_08786cztM0_level2_quad_clean.evt |
| Size (bytes) | 469,938,240 | 102,009,600 |
| Size | 448.2 MB | 97.3 MB |
| Events in quadrant A | 3,393,304 | 672,148 |
| Events in quadrant B | 3,112,795 | 681,308 |
| Events in quadrant C | 3,064,974 | 670,940 |
| Events in quadrant D | 4,242,116 | 634,307 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14026 | 3 |
| B | 0 | 13175 | 2 |
| C | 0 | 13060 | 2 |
| D | 0 | 16977 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 126 | 0 |
| B | 0 | 126 | 0 |
| C | 0 | 126 | 0 |
| D | 0 | 126 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13 | 0 |
| B | 0 | 13 | 0 |
| C | 0 | 13 | 0 |
| D | 0 | 14 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6168 | 90 | 1.459144% |
| B | 6168 | 70 | 1.134890% |
| C | 6168 | 61 | 0.988975% |
| D | 6168 | 334 | 5.415045% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7483 | 6168 | 8 | 8 | 0.11% | 0.13% |  |
| B | 7483 | 6168 | 0 | 0 | 0.00% | 0.00% |  |
| C | 7483 | 6168 | 2 | 2 | 0.03% | 0.03% |  |
| D | 7483 | 6168 | 215 | 215 | 2.87% | 3.49% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 8 | 5 | 225627 | 1398.48 | 799 | 784 | 160.8 |
| A | 15 | 223 | 57347 | 351.81 | 799 | 784 | 160.8 |
| A | 15 | 239 | 23018 | 138.29 | 799 | 784 | 160.8 |
| B | 4 | 173 | 26570 | 171.52 | 795 | 777 | 150.4 |
| B | 12 | 111 | 16133 | 102.12 | 795 | 777 | 150.4 |
| B | 11 | 111 | 13323 | 83.43 | 795 | 777 | 150.4 |
| C | 14 | 234 | 12793 | 66.86 | 780 | 785 | 179.6 |
| C | 9 | 68 | 6882 | 33.95 | 780 | 785 | 179.6 |
| C | 13 | 61 | 5749 | 27.64 | 780 | 785 | 179.6 |
| D | 2 | 16 | 544598 | 2779.1 | 772 | 753 | 195.7 |
| D | 2 | 152 | 461850 | 2356.25 | 772 | 753 | 195.7 |
| D | 9 | 64 | 80887 | 409.49 | 772 | 753 | 195.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
