| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A03_135T01_9000001226_08810cztM0_level2.evt | modeM0/AS1A03_135T01_9000001226_08810cztM0_level2_quad_clean.evt |
| Size (bytes) | 467,847,360 | 75,297,600 |
| Size | 446.2 MB | 71.8 MB |
| Events in quadrant A | 3,365,303 | 461,963 |
| Events in quadrant B | 3,784,734 | 458,868 |
| Events in quadrant C | 3,087,635 | 454,036 |
| Events in quadrant D | 3,480,247 | 442,406 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 136 | 0 |
| B | 0 | 136 | 0 |
| C | 0 | 136 | 0 |
| D | 0 | 136 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14085 | 3 |
| B | 0 | 15498 | 2 |
| C | 0 | 13575 | 2 |
| D | 0 | 14702 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12 | 0 |
| B | 0 | 12 | 0 |
| C | 0 | 12 | 0 |
| D | 0 | 13 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6632 | 61 | 0.919783% |
| B | 6632 | 204 | 3.075995% |
| C | 6632 | 35 | 0.527744% |
| D | 6632 | 108 | 1.628468% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7687 | 6632 | 2 | 2 | 0.03% | 0.03% |  |
| B | 7687 | 6632 | 106 | 106 | 1.38% | 1.60% |  |
| C | 7687 | 6632 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7687 | 6632 | 56 | 56 | 0.73% | 0.84% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 8 | 5 | 204549 | 1225.7 | 819 | 802 | 166.2 |
| A | 13 | 251 | 13042 | 73.63 | 819 | 802 | 166.2 |
| A | 0 | 226 | 7593 | 40.85 | 819 | 802 | 166.2 |
| B | 10 | 16 | 609666 | 3966.92 | 810 | 791 | 153.5 |
| B | 12 | 111 | 16929 | 105.14 | 810 | 791 | 153.5 |
| B | 11 | 111 | 13864 | 85.17 | 810 | 791 | 153.5 |
| C | 9 | 54 | 7506 | 36.63 | 789 | 794 | 183.2 |
| C | 13 | 61 | 5893 | 27.83 | 789 | 794 | 183.2 |
| C | 8 | 222 | 2749 | 10.67 | 789 | 794 | 183.2 |
| D | 7 | 71 | 203093 | 1062.79 | 783 | 763 | 190.4 |
| D | 2 | 152 | 198555 | 1038.96 | 783 | 763 | 190.4 |
| D | 5 | 233 | 50459 | 261.04 | 783 | 763 | 190.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
