| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A03_025T08_9000001248_08982cztM0_level2.evt | modeM0/AS1A03_025T08_9000001248_08982cztM0_level2_quad_clean.evt |
| Size (bytes) | 601,176,960 | 113,316,480 |
| Size | 573.3 MB | 108.1 MB |
| Events in quadrant A | 4,964,360 | 709,078 |
| Events in quadrant B | 4,244,896 | 722,644 |
| Events in quadrant C | 4,179,294 | 711,892 |
| Events in quadrant D | 4,235,513 | 691,496 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16 | 0 |
| B | 0 | 16 | 0 |
| C | 0 | 16 | 0 |
| D | 0 | 16 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 20466 | 5 |
| B | 0 | 18230 | 6 |
| C | 0 | 18340 | 6 |
| D | 0 | 18583 | 4 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 174 | 0 |
| B | 0 | 174 | 0 |
| C | 0 | 174 | 0 |
| D | 0 | 174 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 8599 | 210 | 2.442144% |
| B | 8598 | 55 | 0.639684% |
| C | 8598 | 70 | 0.814143% |
| D | 8599 | 46 | 0.534946% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 10085 | 8602 | 89 | 89 | 0.88% | 1.03% |  |
| B | 10085 | 8602 | 1 | 1 | 0.01% | 0.01% |  |
| C | 10085 | 8602 | 35 | 35 | 0.35% | 0.41% |  |
| D | 10085 | 8602 | 22 | 22 | 0.22% | 0.26% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 8 | 5 | 1004981 | 4820.65 | 1018 | 995 | 208.3 |
| A | 13 | 248 | 17007 | 76.88 | 1018 | 995 | 208.3 |
| A | 15 | 174 | 13805 | 61.51 | 1018 | 995 | 208.3 |
| B | 0 | 219 | 83567 | 415.14 | 1027 | 1001 | 198.9 |
| B | 4 | 173 | 38522 | 188.66 | 1027 | 1001 | 198.9 |
| B | 0 | 230 | 36295 | 177.46 | 1027 | 1001 | 198.9 |
| C | 4 | 254 | 171055 | 736.09 | 994 | 998 | 231.0 |
| C | 14 | 234 | 121350 | 520.94 | 994 | 998 | 231.0 |
| C | 13 | 61 | 7610 | 28.62 | 994 | 998 | 231.0 |
| D | 7 | 71 | 163788 | 617.47 | 987 | 965 | 263.7 |
| D | 1 | 52 | 105846 | 397.74 | 987 | 965 | 263.7 |
| D | 2 | 14 | 60465 | 225.64 | 987 | 965 | 263.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
