| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G07_029T02_9000001256_09027cztM0_level2.evt | modeM0/AS1G07_029T02_9000001256_09027cztM0_level2_quad_clean.evt |
| Size (bytes) | 596,476,800 | 85,052,160 |
| Size | 568.8 MB | 81.1 MB |
| Events in quadrant A | 6,927,596 | 513,395 |
| Events in quadrant B | 3,700,867 | 534,543 |
| Events in quadrant C | 3,230,764 | 524,807 |
| Events in quadrant D | 3,723,508 | 507,568 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 146 | 0 |
| B | 0 | 146 | 0 |
| C | 0 | 146 | 0 |
| D | 0 | 146 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 20 | 0 |
| B | 0 | 20 | 0 |
| C | 0 | 20 | 0 |
| D | 0 | 20 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 25495 | 12 |
| B | 0 | 15644 | 20 |
| C | 0 | 14476 | 2 |
| D | 0 | 16107 | 4 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7115 | 713 | 10.021082% |
| B | 7109 | 79 | 1.111267% |
| C | 7117 | 13 | 0.182661% |
| D | 7116 | 87 | 1.222597% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 9127 | 7119 | 594 | 594 | 6.51% | 8.34% |  |
| B | 9127 | 7118 | 25 | 25 | 0.27% | 0.35% |  |
| C | 9127 | 7119 | 3 | 3 | 0.03% | 0.04% |  |
| D | 9127 | 7119 | 65 | 65 | 0.71% | 0.91% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 8 | 5 | 3666775 | 21587.95 | 828 | 809 | 169.8 |
| A | 1 | 162 | 43346 | 250.49 | 828 | 809 | 169.8 |
| A | 1 | 178 | 8537 | 45.51 | 828 | 809 | 169.8 |
| B | 4 | 48 | 241312 | 1460.56 | 850 | 828 | 164.7 |
| B | 6 | 51 | 93969 | 565.68 | 850 | 828 | 164.7 |
| B | 0 | 214 | 31130 | 184.04 | 850 | 828 | 164.7 |
| C | 14 | 234 | 19323 | 96.8 | 823 | 826 | 191.1 |
| C | 13 | 61 | 6304 | 28.67 | 823 | 826 | 191.1 |
| C | 3 | 254 | 2805 | 10.36 | 823 | 826 | 191.1 |
| D | 1 | 52 | 211141 | 1020.73 | 813 | 792 | 206.1 |
| D | 2 | 14 | 131186 | 632.74 | 813 | 792 | 206.1 |
| D | 6 | 225 | 97903 | 471.24 | 813 | 792 | 206.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
