| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G07_029T02_9000001256_09033cztM0_level2.evt | modeM0/AS1G07_029T02_9000001256_09033cztM0_level2_quad_clean.evt |
| Size (bytes) | 595,149,120 | 88,856,640 |
| Size | 567.6 MB | 84.7 MB |
| Events in quadrant A | 5,734,621 | 567,252 |
| Events in quadrant B | 3,394,151 | 587,486 |
| Events in quadrant C | 3,142,237 | 569,916 |
| Events in quadrant D | 5,308,400 | 508,049 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 138 | 0 |
| B | 0 | 138 | 0 |
| C | 0 | 138 | 0 |
| D | 0 | 138 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 23 | 0 |
| B | 0 | 23 | 0 |
| C | 0 | 23 | 0 |
| D | 0 | 23 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 21550 | 31 |
| B | 0 | 14131 | 28 |
| C | 0 | 13706 | 18 |
| D | 0 | 20077 | 97 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6561 | 345 | 5.258345% |
| B | 6558 | 208 | 3.171699% |
| C | 6561 | 135 | 2.057613% |
| D | 6544 | 800 | 12.224939% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 8934 | 6569 | 86 | 86 | 0.96% | 1.31% |  |
| B | 8934 | 6569 | 11 | 11 | 0.12% | 0.17% |  |
| C | 8934 | 6569 | 0 | 0 | 0.00% | 0.00% |  |
| D | 8934 | 6565 | 593 | 593 | 6.64% | 9.03% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 8 | 5 | 2431663 | 14339.56 | 831 | 813 | 169.5 |
| A | 1 | 162 | 55642 | 323.44 | 831 | 813 | 169.5 |
| A | 3 | 1 | 15565 | 87.02 | 831 | 813 | 169.5 |
| B | 10 | 16 | 57747 | 357.58 | 832 | 814 | 159.2 |
| B | 10 | 245 | 25100 | 152.53 | 832 | 814 | 159.2 |
| B | 0 | 219 | 20287 | 122.31 | 832 | 814 | 159.2 |
| C | 13 | 61 | 6119 | 28.37 | 805 | 808 | 187.2 |
| C | 14 | 67 | 3252 | 13.05 | 805 | 808 | 187.2 |
| C | 8 | 222 | 2017 | 6.46 | 805 | 808 | 187.2 |
| D | 1 | 52 | 1681607 | 8868.5 | 762 | 741 | 189.5 |
| D | 6 | 225 | 598216 | 3152.37 | 762 | 741 | 189.5 |
| D | 7 | 71 | 46733 | 242.66 | 762 | 741 | 189.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
