| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A03_046T01_9000001260_09060cztM0_level2.evt | modeM0/AS1A03_046T01_9000001260_09060cztM0_level2_quad_clean.evt |
| Size (bytes) | 396,722,880 | 62,403,840 |
| Size | 378.3 MB | 59.5 MB |
| Events in quadrant A | 2,921,179 | 494,265 |
| Events in quadrant B | 1,001,012 | 98,629 |
| Events in quadrant C | 2,802,569 | 495,680 |
| Events in quadrant D | 4,960,032 | 460,442 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 122 | 6 |
| B | 0 | 122 | 4 |
| C | 0 | 122 | 2 |
| D | 0 | 122 | 4 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13 | 0 |
| B | 0 | 13 | 0 |
| C | 0 | 13 | 0 |
| D | 0 | 13 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12553 | 514 |
| B | 0 | 12514 | 8328 |
| C | 0 | 12425 | 581 |
| D | 0 | 20325 | 1791 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5764 | 51 | 0.884802% |
| B | 2044 | 1 | 0.048924% |
| C | 5721 | 49 | 0.856494% |
| D | 5594 | 467 | 8.348230% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7309 | 5975 | 0 | 0 | 0.00% | 0.00% |  |
| B | 2236 | 2204 | 0 | 0 | 0.00% | 0.00% |  |
| C | 7310 | 5958 | 2 | 2 | 0.03% | 0.03% |  |
| D | 7310 | 5886 | 341 | 341 | 4.66% | 5.79% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 8 | 5 | 77206 | 516.71 | 728 | 714 | 148.0 |
| A | 1 | 162 | 20059 | 130.68 | 728 | 714 | 148.0 |
| A | 15 | 239 | 7797 | 47.85 | 728 | 714 | 148.0 |
| B | 0 | 229 | 6797 | 134.62 | 255 | 249 | 48.6 |
| B | 12 | 111 | 4815 | 93.87 | 255 | 249 | 48.6 |
| B | 11 | 111 | 4032 | 77.77 | 255 | 249 | 48.6 |
| C | 14 | 234 | 12228 | 71.49 | 713 | 718 | 161.0 |
| C | 3 | 254 | 7197 | 40.24 | 713 | 718 | 161.0 |
| C | 13 | 61 | 5450 | 29.39 | 713 | 718 | 161.0 |
| D | 1 | 52 | 1372165 | 8078.16 | 671 | 655 | 169.8 |
| D | 2 | 14 | 539867 | 3175.94 | 671 | 655 | 169.8 |
| D | 13 | 104 | 415397 | 2442.82 | 671 | 655 | 169.8 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
