| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G07_057T04_9000001264_09073cztM0_level2.evt | modeM0/AS1G07_057T04_9000001264_09073cztM0_level2_quad_clean.evt |
| Size (bytes) | 339,096,960 | 53,507,520 |
| Size | 323.4 MB | 51.0 MB |
| Events in quadrant A | 2,955,188 | 325,633 |
| Events in quadrant B | 2,342,453 | 333,001 |
| Events in quadrant C | 2,231,914 | 322,083 |
| Events in quadrant D | 2,422,139 | 311,375 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 94 | 0 |
| B | 0 | 94 | 0 |
| C | 0 | 94 | 0 |
| D | 0 | 94 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11865 | 2 |
| B | 0 | 9830 | 1 |
| C | 0 | 9676 | 1 |
| D | 0 | 10279 | 1 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13 | 0 |
| B | 0 | 13 | 0 |
| C | 0 | 13 | 0 |
| D | 0 | 13 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 4671 | 31 | 0.663669% |
| B | 4671 | 17 | 0.363948% |
| C | 4671 | 4 | 0.085635% |
| D | 4671 | 41 | 0.877756% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 5941 | 4672 | 15 | 15 | 0.25% | 0.32% |  |
| B | 5941 | 4672 | 7 | 7 | 0.12% | 0.15% |  |
| C | 5941 | 4672 | 2 | 2 | 0.03% | 0.04% |  |
| D | 5941 | 4672 | 31 | 31 | 0.52% | 0.66% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 8 | 5 | 677230 | 5826.49 | 575 | 565 | 116.1 |
| A | 1 | 162 | 22687 | 190.48 | 575 | 565 | 116.1 |
| A | 15 | 239 | 15657 | 129.95 | 575 | 565 | 116.1 |
| B | 4 | 80 | 24370 | 216.94 | 580 | 568 | 109.7 |
| B | 4 | 173 | 18088 | 159.69 | 580 | 568 | 109.7 |
| B | 10 | 16 | 16241 | 142.85 | 580 | 568 | 109.7 |
| C | 14 | 234 | 65346 | 505.02 | 555 | 558 | 128.3 |
| C | 13 | 61 | 4302 | 29.18 | 555 | 558 | 128.3 |
| C | 14 | 67 | 1425 | 6.76 | 555 | 558 | 128.3 |
| D | 2 | 14 | 128312 | 915.53 | 550 | 537 | 139.6 |
| D | 1 | 52 | 69459 | 493.84 | 550 | 537 | 139.6 |
| D | 7 | 71 | 55904 | 396.72 | 550 | 537 | 139.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
