| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1C02_027T01_9000001280_09164cztM0_level2.evt | modeM0/AS1C02_027T01_9000001280_09164cztM0_level2_quad_clean.evt |
| Size (bytes) | 439,833,600 | 117,783,360 |
| Size | 419.5 MB | 112.3 MB |
| Events in quadrant A | 3,735,639 | 778,447 |
| Events in quadrant B | 3,071,700 | 793,991 |
| Events in quadrant C | 2,806,570 | 793,537 |
| Events in quadrant D | 3,279,895 | 763,486 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15159 | 2 |
| B | 0 | 13327 | 1 |
| C | 0 | 12760 | 1 |
| D | 0 | 14157 | 1 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 9 | 0 |
| B | 0 | 9 | 0 |
| C | 0 | 9 | 0 |
| D | 0 | 9 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 130 | 0 |
| B | 0 | 130 | 0 |
| C | 0 | 130 | 0 |
| D | 0 | 130 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6265 | 97 | 1.548284% |
| B | 6265 | 83 | 1.324820% |
| C | 6265 | 65 | 1.037510% |
| D | 6265 | 172 | 2.745411% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7220 | 6265 | 9 | 9 | 0.12% | 0.14% |  |
| B | 7220 | 6265 | 11 | 11 | 0.15% | 0.18% |  |
| C | 7220 | 6265 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7220 | 6265 | 121 | 121 | 1.68% | 1.93% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 8 | 5 | 450437 | 3070.3 | 727 | 712 | 146.5 |
| A | 15 | 174 | 372431 | 2537.75 | 727 | 712 | 146.5 |
| A | 1 | 162 | 45196 | 303.69 | 727 | 712 | 146.5 |
| B | 3 | 220 | 78311 | 570.23 | 727 | 708 | 136.1 |
| B | 8 | 234 | 48432 | 350.68 | 727 | 708 | 136.1 |
| B | 0 | 229 | 41037 | 296.34 | 727 | 708 | 136.1 |
| C | 13 | 61 | 5364 | 28.22 | 718 | 719 | 164.6 |
| C | 12 | 4 | 3062 | 14.23 | 718 | 719 | 164.6 |
| C | 8 | 222 | 2553 | 11.14 | 718 | 719 | 164.6 |
| D | 1 | 52 | 246833 | 1406.4 | 710 | 691 | 175.0 |
| D | 12 | 233 | 220408 | 1255.42 | 710 | 691 | 175.0 |
| D | 7 | 71 | 49421 | 278.43 | 710 | 691 | 175.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
