| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1C02_041T02_9000001282_09176cztM0_level2.evt | modeM0/AS1C02_041T02_9000001282_09176cztM0_level2_quad_clean.evt |
| Size (bytes) | 478,998,720 | 81,550,080 |
| Size | 456.8 MB | 77.8 MB |
| Events in quadrant A | 3,330,298 | 516,308 |
| Events in quadrant B | 3,201,781 | 530,568 |
| Events in quadrant C | 3,048,832 | 514,575 |
| Events in quadrant D | 4,508,204 | 478,501 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 126 | 0 |
| B | 0 | 126 | 0 |
| C | 0 | 126 | 0 |
| D | 0 | 126 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13626 | 7 |
| B | 0 | 13311 | 7 |
| C | 0 | 12785 | 10 |
| D | 0 | 17423 | 4 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 23 | 0 |
| B | 0 | 23 | 0 |
| C | 0 | 23 | 0 |
| D | 0 | 24 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6147 | 28 | 0.455507% |
| B | 6147 | 49 | 0.797137% |
| C | 6145 | 14 | 0.227828% |
| D | 6148 | 293 | 4.765777% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7514 | 6150 | 1 | 1 | 0.01% | 0.02% |  |
| B | 7514 | 6150 | 5 | 5 | 0.07% | 0.08% |  |
| C | 7514 | 6150 | 10 | 10 | 0.13% | 0.16% |  |
| D | 7514 | 6150 | 325 | 325 | 4.33% | 5.28% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 8 | 5 | 241789 | 1547.24 | 772 | 757 | 155.8 |
| A | 1 | 162 | 44907 | 283.41 | 772 | 757 | 155.8 |
| A | 13 | 251 | 20777 | 128.51 | 772 | 757 | 155.8 |
| B | 8 | 234 | 81238 | 547.78 | 783 | 765 | 146.9 |
| B | 0 | 230 | 16700 | 108.47 | 783 | 765 | 146.9 |
| B | 12 | 111 | 15379 | 99.48 | 783 | 765 | 146.9 |
| C | 9 | 68 | 102422 | 589.09 | 753 | 759 | 172.6 |
| C | 13 | 61 | 5802 | 29.22 | 753 | 759 | 172.6 |
| C | 12 | 4 | 3546 | 16.15 | 753 | 759 | 172.6 |
| D | 1 | 52 | 1590135 | 8379.02 | 729 | 711 | 189.7 |
| D | 7 | 71 | 50475 | 262.34 | 729 | 711 | 189.7 |
| D | 2 | 14 | 44803 | 232.44 | 729 | 711 | 189.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
