| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1C02_041T02_9000001282_09186cztM0_level2.evt | modeM0/AS1C02_041T02_9000001282_09186cztM0_level2_quad_clean.evt |
| Size (bytes) | 479,485,440 | 89,254,080 |
| Size | 457.3 MB | 85.1 MB |
| Events in quadrant A | 4,590,859 | 567,889 |
| Events in quadrant B | 3,354,127 | 572,194 |
| Events in quadrant C | 2,972,281 | 555,055 |
| Events in quadrant D | 3,152,953 | 544,460 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 132 | 0 |
| B | 0 | 132 | 0 |
| C | 0 | 132 | 0 |
| D | 0 | 132 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 18354 | 3 |
| B | 0 | 14381 | 2 |
| C | 0 | 13589 | 2 |
| D | 0 | 14112 | 5 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 18 | 0 |
| B | 0 | 18 | 0 |
| C | 0 | 18 | 0 |
| D | 0 | 19 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6654 | 111 | 1.668170% |
| B | 6654 | 59 | 0.886685% |
| C | 6654 | 22 | 0.330628% |
| D | 6653 | 31 | 0.465955% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7684 | 6655 | 15 | 15 | 0.20% | 0.23% |  |
| B | 7684 | 6655 | 29 | 29 | 0.38% | 0.44% |  |
| C | 7684 | 6655 | 10 | 10 | 0.13% | 0.15% |  |
| D | 7684 | 6655 | 14 | 14 | 0.18% | 0.21% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 8 | 5 | 1136137 | 7138.37 | 786 | 770 | 159.1 |
| A | 1 | 162 | 156454 | 978.83 | 786 | 770 | 159.1 |
| A | 15 | 223 | 94785 | 591.1 | 786 | 770 | 159.1 |
| B | 8 | 234 | 180292 | 1171.74 | 792 | 774 | 153.2 |
| B | 0 | 230 | 48231 | 309.76 | 792 | 774 | 153.2 |
| B | 0 | 246 | 23216 | 146.48 | 792 | 774 | 153.2 |
| C | 14 | 234 | 31115 | 171.37 | 753 | 756 | 177.2 |
| C | 13 | 61 | 5772 | 28.31 | 753 | 756 | 177.2 |
| C | 8 | 222 | 3593 | 16.01 | 753 | 756 | 177.2 |
| D | 7 | 71 | 74333 | 397.09 | 758 | 734 | 185.3 |
| D | 1 | 52 | 67168 | 358.43 | 758 | 734 | 185.3 |
| D | 2 | 14 | 39961 | 211.64 | 758 | 734 | 185.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
