| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A03_051T01_9000001288_09238cztM0_level2.evt | modeM0/AS1A03_051T01_9000001288_09238cztM0_level2_quad_clean.evt |
| Size (bytes) | 559,316,160 | 88,418,880 |
| Size | 533.4 MB | 84.3 MB |
| Events in quadrant A | 4,705,688 | 535,159 |
| Events in quadrant B | 3,984,967 | 538,111 |
| Events in quadrant C | 3,709,969 | 529,925 |
| Events in quadrant D | 3,996,073 | 519,039 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 162 | 0 |
| B | 0 | 162 | 0 |
| C | 0 | 162 | 0 |
| D | 0 | 162 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 19083 | 46 |
| B | 0 | 17053 | 24 |
| C | 0 | 16706 | 21 |
| D | 0 | 17605 | 15 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12 | 0 |
| B | 0 | 12 | 0 |
| C | 0 | 12 | 0 |
| D | 0 | 12 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7985 | 196 | 2.454602% |
| B | 7994 | 179 | 2.239179% |
| C | 7995 | 123 | 1.538462% |
| D | 7998 | 193 | 2.413103% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 9184 | 8006 | 12 | 12 | 0.13% | 0.15% |  |
| B | 9184 | 8006 | 9 | 9 | 0.10% | 0.11% |  |
| C | 9184 | 8006 | 4 | 4 | 0.04% | 0.05% |  |
| D | 9184 | 8006 | 69 | 69 | 0.75% | 0.86% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 8 | 5 | 702842 | 3539.79 | 967 | 946 | 198.3 |
| A | 1 | 162 | 89156 | 444.86 | 967 | 946 | 198.3 |
| A | 0 | 8 | 53431 | 264.69 | 967 | 946 | 198.3 |
| B | 0 | 214 | 61452 | 319.59 | 976 | 951 | 189.3 |
| B | 10 | 252 | 43716 | 225.9 | 976 | 951 | 189.3 |
| B | 0 | 230 | 20769 | 104.69 | 976 | 951 | 189.3 |
| C | 12 | 4 | 18767 | 80.32 | 945 | 948 | 221.8 |
| C | 13 | 61 | 7090 | 27.69 | 945 | 948 | 221.8 |
| C | 8 | 222 | 6365 | 24.42 | 945 | 948 | 221.8 |
| D | 7 | 71 | 229406 | 913.36 | 937 | 911 | 250.2 |
| D | 1 | 52 | 83697 | 330.92 | 937 | 911 | 250.2 |
| D | 12 | 233 | 49049 | 192.42 | 937 | 911 | 250.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
