| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G07_003T01_9000001290_09244cztM0_level2.evt | modeM0/AS1G07_003T01_9000001290_09244cztM0_level2_quad_clean.evt |
| Size (bytes) | 1,185,883,200 | 195,232,320 |
| Size | 1.1 GB | 186.2 MB |
| Events in quadrant A | 12,200,023 | 1,220,728 |
| Events in quadrant B | 8,011,333 | 1,229,102 |
| Events in quadrant C | 7,173,576 | 1,197,060 |
| Events in quadrant D | 7,473,373 | 1,187,909 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 46762 | 6 |
| B | 0 | 33948 | 3 |
| C | 0 | 32426 | 3 |
| D | 0 | 33572 | 3 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 26 | 0 |
| B | 0 | 26 | 0 |
| C | 0 | 26 | 0 |
| D | 0 | 26 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 318 | 0 |
| B | 0 | 318 | 0 |
| C | 0 | 318 | 0 |
| D | 0 | 318 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 15629 | 1334 | 8.535415% |
| B | 15630 | 166 | 1.062060% |
| C | 15630 | 119 | 0.761356% |
| D | 15630 | 229 | 1.465131% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 18205 | 15633 | 1045 | 1045 | 5.74% | 6.68% |  |
| B | 18205 | 15633 | 42 | 42 | 0.23% | 0.27% |  |
| C | 18205 | 15633 | 52 | 52 | 0.29% | 0.33% |  |
| D | 18205 | 15633 | 139 | 139 | 0.76% | 0.89% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 8 | 5 | 2721124 | 7559.19 | 1772 | 1737 | 359.7 |
| A | 15 | 223 | 1135795 | 3152.39 | 1772 | 1737 | 359.7 |
| A | 15 | 174 | 821098 | 2277.61 | 1772 | 1737 | 359.7 |
| B | 4 | 48 | 285388 | 808.25 | 1844 | 1801 | 350.9 |
| B | 6 | 51 | 179505 | 506.48 | 1844 | 1801 | 350.9 |
| B | 0 | 214 | 146252 | 411.7 | 1844 | 1801 | 350.9 |
| C | 14 | 234 | 256084 | 620.51 | 1768 | 1776 | 409.8 |
| C | 13 | 61 | 13499 | 28.6 | 1768 | 1776 | 409.8 |
| C | 8 | 222 | 12728 | 26.72 | 1768 | 1776 | 409.8 |
| D | 7 | 71 | 428369 | 888.04 | 1763 | 1721 | 480.4 |
| D | 1 | 52 | 154563 | 318.13 | 1763 | 1721 | 480.4 |
| D | 12 | 233 | 89548 | 182.81 | 1763 | 1721 | 480.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
