| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G07_077T01_9000001306_09289cztM0_level2.evt | modeM0/AS1G07_077T01_9000001306_09289cztM0_level2_quad_clean.evt |
| Size (bytes) | 620,170,560 | 98,680,320 |
| Size | 591.4 MB | 94.1 MB |
| Events in quadrant A | 4,918,143 | 605,248 |
| Events in quadrant B | 3,775,612 | 631,523 |
| Events in quadrant C | 3,505,978 | 622,027 |
| Events in quadrant D | 6,042,609 | 576,230 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 19526 | 2 |
| B | 0 | 16466 | 1 |
| C | 0 | 16185 | 1 |
| D | 0 | 23290 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 162 | 0 |
| B | 0 | 162 | 0 |
| C | 0 | 162 | 0 |
| D | 0 | 162 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 2 | 0 |
| B | 0 | 2 | 0 |
| C | 0 | 2 | 0 |
| D | 0 | 2 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7953 | 333 | 4.187099% |
| B | 7953 | 171 | 2.150132% |
| C | 7953 | 114 | 1.433421% |
| D | 7953 | 770 | 9.681881% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 8218 | 7954 | 139 | 139 | 1.69% | 1.75% |  |
| B | 8218 | 7954 | 2 | 2 | 0.02% | 0.03% |  |
| C | 8218 | 7954 | 0 | 0 | 0.00% | 0.00% |  |
| D | 8218 | 7954 | 583 | 583 | 7.09% | 7.33% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 8 | 5 | 799944 | 4337.7 | 900 | 879 | 184.2 |
| A | 4 | 2 | 418402 | 2266.51 | 900 | 879 | 184.2 |
| A | 5 | 16 | 86227 | 463.31 | 900 | 879 | 184.2 |
| B | 0 | 214 | 93387 | 524.66 | 914 | 889 | 176.3 |
| B | 0 | 219 | 64296 | 359.65 | 914 | 889 | 176.3 |
| B | 8 | 234 | 30308 | 166.87 | 914 | 889 | 176.3 |
| C | 14 | 234 | 15175 | 69.52 | 890 | 894 | 205.4 |
| C | 8 | 222 | 9019 | 39.55 | 890 | 894 | 205.4 |
| C | 13 | 61 | 6651 | 28.02 | 890 | 894 | 205.4 |
| D | 1 | 52 | 1878936 | 8963.02 | 852 | 829 | 209.5 |
| D | 12 | 233 | 659205 | 3142.01 | 852 | 829 | 209.5 |
| D | 7 | 71 | 103807 | 491.45 | 852 | 829 | 209.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
