| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G07_076T03_9000001314_09306cztM0_level2.evt | modeM0/AS1G07_076T03_9000001314_09306cztM0_level2_quad_clean.evt |
| Size (bytes) | 260,657,280 | 52,848,000 |
| Size | 248.6 MB | 50.4 MB |
| Events in quadrant A | 1,943,163 | 329,750 |
| Events in quadrant B | 1,930,810 | 341,282 |
| Events in quadrant C | 1,927,301 | 333,149 |
| Events in quadrant D | 1,828,650 | 323,163 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 80 | 0 |
| B | 0 | 80 | 0 |
| C | 0 | 80 | 0 |
| D | 0 | 80 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13 | 0 |
| B | 0 | 13 | 0 |
| C | 0 | 13 | 0 |
| D | 0 | 13 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 8255 | 67 |
| B | 0 | 8262 | 60 |
| C | 0 | 8379 | 101 |
| D | 0 | 8176 | 79 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 3861 | 30 | 0.777001% |
| B | 3864 | 27 | 0.698758% |
| C | 3851 | 39 | 1.012724% |
| D | 3854 | 18 | 0.467047% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 5201 | 3889 | 1 | 1 | 0.02% | 0.03% |  |
| B | 5201 | 3891 | 0 | 0 | 0.00% | 0.00% |  |
| C | 5201 | 3889 | 10 | 10 | 0.19% | 0.26% |  |
| D | 5201 | 3891 | 3 | 3 | 0.06% | 0.08% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 8 | 5 | 39349 | 397.11 | 483 | 473 | 97.9 |
| A | 1 | 162 | 25133 | 251.9 | 483 | 473 | 97.9 |
| A | 1 | 178 | 6170 | 58.19 | 483 | 473 | 97.9 |
| B | 0 | 219 | 17945 | 186.04 | 488 | 476 | 93.9 |
| B | 12 | 111 | 10474 | 106.47 | 488 | 476 | 93.9 |
| B | 3 | 209 | 8849 | 89.17 | 488 | 476 | 93.9 |
| C | 14 | 234 | 64614 | 583.45 | 470 | 473 | 109.9 |
| C | 9 | 68 | 12507 | 109.47 | 470 | 473 | 109.9 |
| C | 14 | 67 | 9533 | 82.41 | 470 | 473 | 109.9 |
| D | 1 | 52 | 17127 | 145.53 | 467 | 456 | 114.6 |
| D | 1 | 31 | 16523 | 140.26 | 467 | 456 | 114.6 |
| D | 2 | 14 | 13896 | 117.32 | 467 | 456 | 114.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
