| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G07_077T04_9000001312_09304cztM0_level2.evt | modeM0/AS1G07_077T04_9000001312_09304cztM0_level2_quad_clean.evt |
| Size (bytes) | 455,760,000 | 98,596,800 |
| Size | 434.6 MB | 94.0 MB |
| Events in quadrant A | 3,601,970 | 630,954 |
| Events in quadrant B | 3,273,073 | 645,341 |
| Events in quadrant C | 3,289,515 | 639,225 |
| Events in quadrant D | 3,200,720 | 621,343 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12 | 0 |
| B | 0 | 12 | 0 |
| C | 0 | 12 | 0 |
| D | 0 | 12 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 128 | 0 |
| B | 0 | 128 | 0 |
| C | 0 | 128 | 0 |
| D | 0 | 128 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15067 | 2 |
| B | 0 | 14108 | 1 |
| C | 0 | 14220 | 1 |
| D | 0 | 14043 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6448 | 138 | 2.140199% |
| B | 6448 | 58 | 0.899504% |
| C | 6448 | 51 | 0.790943% |
| D | 6448 | 92 | 1.426799% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7578 | 6449 | 62 | 62 | 0.82% | 0.96% |  |
| B | 7578 | 6449 | 4 | 4 | 0.05% | 0.06% |  |
| C | 7578 | 6449 | 6 | 6 | 0.08% | 0.09% |  |
| D | 7578 | 6449 | 31 | 31 | 0.41% | 0.48% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 8 | 5 | 324679 | 2050.27 | 775 | 758 | 158.0 |
| A | 15 | 239 | 158196 | 996.51 | 775 | 758 | 158.0 |
| A | 5 | 16 | 69345 | 434.12 | 775 | 758 | 158.0 |
| B | 0 | 219 | 88932 | 597.63 | 781 | 761 | 147.5 |
| B | 0 | 214 | 82534 | 554.26 | 781 | 761 | 147.5 |
| B | 8 | 234 | 36412 | 241.65 | 781 | 761 | 147.5 |
| C | 9 | 68 | 277872 | 1569.31 | 768 | 772 | 176.6 |
| C | 14 | 67 | 15192 | 81.67 | 768 | 772 | 176.6 |
| C | 13 | 61 | 5714 | 27.99 | 768 | 772 | 176.6 |
| D | 1 | 52 | 167849 | 885.06 | 759 | 740 | 188.8 |
| D | 7 | 71 | 53027 | 276.93 | 759 | 740 | 188.8 |
| D | 2 | 136 | 51599 | 269.36 | 759 | 740 | 188.8 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
