| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A02_178T01_9000001340_09424cztM0_level2.evt | modeM0/AS1A02_178T01_9000001340_09424cztM0_level2_quad_clean.evt |
| Size (bytes) | 518,244,480 | 87,364,800 |
| Size | 494.2 MB | 83.3 MB |
| Events in quadrant A | 3,324,317 | 568,157 |
| Events in quadrant B | 3,205,813 | 568,840 |
| Events in quadrant C | 5,287,411 | 521,097 |
| Events in quadrant D | 3,447,097 | 544,508 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 130 | 0 |
| B | 0 | 130 | 0 |
| C | 0 | 130 | 0 |
| D | 0 | 130 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14046 | 94 |
| B | 0 | 13796 | 79 |
| C | 0 | 20229 | 129 |
| D | 0 | 14626 | 99 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 21 | 0 |
| B | 0 | 21 | 0 |
| C | 0 | 21 | 0 |
| D | 0 | 22 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6340 | 45 | 0.709779% |
| B | 6344 | 50 | 0.788146% |
| C | 6344 | 622 | 9.804540% |
| D | 6340 | 35 | 0.552050% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7515 | 6378 | 2 | 2 | 0.03% | 0.03% |  |
| B | 7515 | 6380 | 7 | 7 | 0.09% | 0.11% |  |
| C | 7515 | 6381 | 506 | 506 | 6.73% | 7.93% |  |
| D | 7515 | 6379 | 26 | 26 | 0.35% | 0.41% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 8 | 5 | 303875 | 1916.18 | 771 | 754 | 158.2 |
| A | 1 | 162 | 22303 | 136.22 | 771 | 754 | 158.2 |
| A | 15 | 174 | 10987 | 64.69 | 771 | 754 | 158.2 |
| B | 0 | 214 | 43548 | 289.38 | 773 | 756 | 147.9 |
| B | 0 | 230 | 40055 | 265.76 | 773 | 756 | 147.9 |
| B | 0 | 219 | 37214 | 246.55 | 773 | 756 | 147.9 |
| C | 4 | 254 | 2386909 | 14344.75 | 716 | 720 | 166.3 |
| C | 9 | 68 | 83978 | 500.51 | 716 | 720 | 166.3 |
| C | 5 | 238 | 16020 | 91.98 | 716 | 720 | 166.3 |
| D | 8 | 195 | 325462 | 1748.44 | 737 | 720 | 185.7 |
| D | 7 | 71 | 128052 | 685.57 | 737 | 720 | 185.7 |
| D | 12 | 227 | 65363 | 348.04 | 737 | 720 | 185.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
