| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G07_030T01_9000001338_09422cztM0_level2.evt | modeM0/AS1G07_030T01_9000001338_09422cztM0_level2_quad_clean.evt |
| Size (bytes) | 646,344,000 | 80,472,960 |
| Size | 616.4 MB | 76.7 MB |
| Events in quadrant A | 3,787,582 | 566,481 |
| Events in quadrant B | 3,208,791 | 579,771 |
| Events in quadrant C | 8,949,725 | 311,802 |
| Events in quadrant D | 3,210,048 | 546,793 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 128 | 0 |
| B | 0 | 128 | 0 |
| C | 0 | 128 | 0 |
| D | 0 | 128 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15430 | 6 |
| B | 0 | 13440 | 5 |
| C | 0 | 30794 | 5 |
| D | 0 | 13460 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 26 | 0 |
| B | 0 | 26 | 0 |
| C | 0 | 26 | 0 |
| D | 0 | 26 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6170 | 121 | 1.961102% |
| B | 6170 | 109 | 1.766613% |
| C | 6170 | 2962 | 48.006483% |
| D | 6171 | 88 | 1.426025% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 8761 | 6173 | 3 | 3 | 0.03% | 0.05% |  |
| B | 8761 | 6173 | 0 | 0 | 0.00% | 0.00% |  |
| C | 8761 | 6170 | 1569 | 1569 | 17.91% | 25.43% |  |
| D | 8761 | 6173 | 5 | 5 | 0.06% | 0.08% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 8 | 5 | 587694 | 3563.94 | 821 | 806 | 164.7 |
| A | 4 | 2 | 15551 | 89.54 | 821 | 806 | 164.7 |
| A | 1 | 162 | 14298 | 81.93 | 821 | 806 | 164.7 |
| B | 12 | 111 | 16743 | 103.13 | 825 | 808 | 154.5 |
| B | 11 | 111 | 13484 | 82.04 | 825 | 808 | 154.5 |
| B | 14 | 111 | 10288 | 61.35 | 825 | 808 | 154.5 |
| C | 4 | 254 | 6774304 | 54936.34 | 541 | 545 | 123.3 |
| C | 9 | 68 | 31349 | 249.83 | 541 | 545 | 123.3 |
| C | 14 | 234 | 26272 | 208.65 | 541 | 545 | 123.3 |
| D | 8 | 195 | 96608 | 474.34 | 803 | 787 | 202.0 |
| D | 7 | 71 | 29112 | 140.22 | 803 | 787 | 202.0 |
| D | 2 | 234 | 26401 | 126.8 | 803 | 787 | 202.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
