| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G07_042T01_9000001360_09580cztM0_level2.evt | modeM0/AS1G07_042T01_9000001360_09580cztM0_level2_quad_clean.evt |
| Size (bytes) | 1,201,023,360 | 196,375,680 |
| Size | 1.1 GB | 187.3 MB |
| Events in quadrant A | 9,035,241 | 1,230,231 |
| Events in quadrant B | 8,087,869 | 1,241,834 |
| Events in quadrant C | 7,610,392 | 1,212,265 |
| Events in quadrant D | 10,558,126 | 1,158,939 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 33 | 0 |
| B | 0 | 33 | 0 |
| C | 0 | 33 | 0 |
| D | 0 | 33 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 37364 | 4 |
| B | 0 | 33907 | 3 |
| C | 0 | 32922 | 3 |
| D | 0 | 41720 | 3 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 328 | 0 |
| B | 0 | 328 | 0 |
| C | 0 | 328 | 0 |
| D | 0 | 328 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 15999 | 272 | 1.700106% |
| B | 15999 | 209 | 1.306332% |
| C | 15999 | 121 | 0.756297% |
| D | 15999 | 768 | 4.800300% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 19429 | 16002 | 4 | 4 | 0.02% | 0.02% |  |
| B | 19429 | 16002 | 17 | 17 | 0.09% | 0.11% |  |
| C | 19429 | 16002 | 7 | 7 | 0.04% | 0.04% |  |
| D | 19429 | 16002 | 572 | 572 | 2.94% | 3.57% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 1 | 162 | 518852 | 1285.0 | 2018 | 1983 | 402.2 |
| A | 1 | 178 | 266917 | 658.66 | 2018 | 1983 | 402.2 |
| A | 1 | 161 | 253631 | 625.63 | 2018 | 1983 | 402.2 |
| B | 10 | 245 | 144562 | 378.66 | 2010 | 1966 | 376.6 |
| B | 15 | 85 | 66473 | 171.3 | 2010 | 1966 | 376.6 |
| B | 4 | 80 | 46714 | 118.83 | 2010 | 1966 | 376.6 |
| C | 14 | 234 | 40605 | 87.06 | 1938 | 1955 | 443.9 |
| C | 13 | 61 | 14277 | 27.76 | 1938 | 1955 | 443.9 |
| C | 9 | 68 | 14247 | 27.69 | 1938 | 1955 | 443.9 |
| D | 1 | 52 | 2546300 | 5201.05 | 1903 | 1865 | 489.2 |
| D | 12 | 233 | 210898 | 427.28 | 1903 | 1865 | 489.2 |
| D | 2 | 136 | 111724 | 224.56 | 1903 | 1865 | 489.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
