| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G05_238T01_9000001364_09596cztM0_level2.evt | modeM0/AS1G05_238T01_9000001364_09596cztM0_level2_quad_clean.evt |
| Size (bytes) | 540,990,720 | 73,693,440 |
| Size | 515.9 MB | 70.3 MB |
| Events in quadrant A | 4,139,460 | 452,949 |
| Events in quadrant B | 3,543,857 | 457,407 |
| Events in quadrant C | 3,276,951 | 440,139 |
| Events in quadrant D | 4,981,020 | 425,252 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16583 | 3 |
| B | 0 | 14344 | 2 |
| C | 0 | 13609 | 2 |
| D | 0 | 18967 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 132 | 0 |
| B | 0 | 132 | 0 |
| C | 0 | 132 | 0 |
| D | 0 | 132 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15 | 0 |
| B | 0 | 15 | 0 |
| C | 0 | 15 | 0 |
| D | 0 | 16 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6533 | 197 | 3.015460% |
| B | 6533 | 111 | 1.699066% |
| C | 6533 | 62 | 0.949028% |
| D | 6533 | 392 | 6.000306% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7853 | 6534 | 5 | 5 | 0.06% | 0.08% |  |
| B | 7853 | 6534 | 6 | 6 | 0.08% | 0.09% |  |
| C | 7853 | 6534 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7853 | 6534 | 340 | 340 | 4.33% | 5.20% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 1 | 162 | 287721 | 1625.65 | 883 | 870 | 176.5 |
| A | 1 | 178 | 144222 | 812.41 | 883 | 870 | 176.5 |
| A | 1 | 161 | 137433 | 773.93 | 883 | 870 | 176.5 |
| B | 0 | 214 | 58372 | 349.26 | 875 | 858 | 164.7 |
| B | 0 | 189 | 35220 | 208.66 | 875 | 858 | 164.7 |
| B | 15 | 85 | 20970 | 122.13 | 875 | 858 | 164.7 |
| C | 13 | 61 | 6201 | 27.61 | 840 | 847 | 193.9 |
| C | 14 | 67 | 2121 | 6.57 | 840 | 847 | 193.9 |
| C | 3 | 202 | 2091 | 6.42 | 840 | 847 | 193.9 |
| D | 1 | 52 | 1288118 | 6066.66 | 838 | 817 | 212.2 |
| D | 13 | 122 | 247336 | 1161.77 | 838 | 817 | 212.2 |
| D | 12 | 233 | 93029 | 434.56 | 838 | 817 | 212.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
