| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G05_238T01_9000001364_09598cztM0_level2.evt | modeM0/AS1G05_238T01_9000001364_09598cztM0_level2_quad_clean.evt |
| Size (bytes) | 508,374,720 | 67,106,880 |
| Size | 484.8 MB | 64.0 MB |
| Events in quadrant A | 3,934,153 | 403,438 |
| Events in quadrant B | 3,377,347 | 400,582 |
| Events in quadrant C | 3,183,339 | 389,353 |
| Events in quadrant D | 4,456,669 | 381,550 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15977 | 3 |
| B | 0 | 14045 | 2 |
| C | 0 | 13588 | 2 |
| D | 0 | 17394 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 132 | 0 |
| B | 0 | 132 | 0 |
| C | 0 | 132 | 0 |
| D | 0 | 132 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11 | 0 |
| B | 0 | 11 | 0 |
| C | 0 | 11 | 0 |
| D | 0 | 12 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6554 | 154 | 2.349710% |
| B | 6554 | 118 | 1.800427% |
| C | 6554 | 78 | 1.190113% |
| D | 6554 | 501 | 7.644187% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7639 | 6555 | 3 | 3 | 0.04% | 0.05% |  |
| B | 7639 | 6555 | 0 | 0 | 0.00% | 0.00% |  |
| C | 7639 | 6555 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7639 | 6555 | 398 | 398 | 5.21% | 6.07% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 1 | 162 | 272111 | 1595.03 | 849 | 833 | 170.1 |
| A | 1 | 178 | 139918 | 817.77 | 849 | 833 | 170.1 |
| A | 1 | 161 | 133116 | 777.78 | 849 | 833 | 170.1 |
| B | 0 | 214 | 48869 | 295.64 | 845 | 826 | 162.5 |
| B | 12 | 111 | 17923 | 105.21 | 845 | 826 | 162.5 |
| B | 11 | 111 | 14767 | 85.79 | 845 | 826 | 162.5 |
| C | 13 | 61 | 6002 | 27.12 | 815 | 820 | 191.1 |
| C | 14 | 225 | 2466 | 8.61 | 815 | 820 | 191.1 |
| C | 3 | 202 | 2039 | 6.38 | 815 | 820 | 191.1 |
| D | 1 | 52 | 951234 | 4709.83 | 807 | 790 | 201.8 |
| D | 13 | 104 | 164179 | 809.66 | 807 | 790 | 201.8 |
| D | 2 | 152 | 94618 | 464.96 | 807 | 790 | 201.8 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
