| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A03_009T01_9000001366_09624cztM0_level2.evt | modeM0/AS1A03_009T01_9000001366_09624cztM0_level2_quad_clean.evt |
| Size (bytes) | 284,855,040 | 43,182,720 |
| Size | 271.7 MB | 41.2 MB |
| Events in quadrant A | 1,904,485 | 259,456 |
| Events in quadrant B | 1,964,533 | 261,778 |
| Events in quadrant C | 1,883,302 | 264,757 |
| Events in quadrant D | 2,612,254 | 249,916 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 4 | 0 |
| B | 0 | 4 | 0 |
| C | 0 | 4 | 0 |
| D | 0 | 5 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 78 | 0 |
| B | 0 | 78 | 0 |
| C | 0 | 78 | 0 |
| D | 0 | 78 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 7971 | 1 |
| B | 0 | 8129 | 1 |
| C | 0 | 7997 | 1 |
| D | 0 | 10446 | 5 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 3836 | 24 | 0.625652% |
| B | 3836 | 35 | 0.912409% |
| C | 3836 | 25 | 0.651721% |
| D | 3835 | 63 | 1.642764% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 3836 | 3836 | 0 | 0 | 0.00% | 0.00% |  |
| B | 3836 | 3836 | 3 | 3 | 0.08% | 0.08% |  |
| C | 3836 | 3836 | 0 | 0 | 0.00% | 0.00% |  |
| D | 3836 | 3836 | 38 | 38 | 0.99% | 0.99% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 248 | 6107 | 56.27 | 492 | 483 | 100.0 |
| A | 3 | 1 | 5606 | 51.25 | 492 | 483 | 100.0 |
| A | 0 | 226 | 4566 | 40.85 | 492 | 483 | 100.0 |
| B | 0 | 214 | 29192 | 314.09 | 491 | 481 | 91.4 |
| B | 10 | 252 | 19682 | 210.05 | 491 | 481 | 91.4 |
| B | 12 | 111 | 9688 | 100.72 | 491 | 481 | 91.4 |
| C | 13 | 61 | 3632 | 28.68 | 482 | 486 | 109.7 |
| C | 14 | 67 | 1237 | 6.85 | 482 | 486 | 109.7 |
| C | 3 | 202 | 1203 | 6.54 | 482 | 486 | 109.7 |
| D | 8 | 195 | 365602 | 3004.77 | 476 | 465 | 121.5 |
| D | 1 | 52 | 256539 | 2107.27 | 476 | 465 | 121.5 |
| D | 10 | 199 | 97046 | 794.78 | 476 | 465 | 121.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
