| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T01_176T01_9000001378_09686cztM0_level2.evt | modeM0/AS1T01_176T01_9000001378_09686cztM0_level2_quad_clean.evt |
| Size (bytes) | 273,905,280 | 42,750,720 |
| Size | 261.2 MB | 40.8 MB |
| Events in quadrant A | 1,792,241 | 261,722 |
| Events in quadrant B | 1,918,318 | 264,601 |
| Events in quadrant C | 1,900,054 | 261,200 |
| Events in quadrant D | 2,434,366 | 247,743 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 7661 | 19 |
| B | 0 | 7946 | 25 |
| C | 0 | 8013 | 26 |
| D | 0 | 9796 | 31 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 76 | 0 |
| B | 0 | 76 | 0 |
| C | 0 | 76 | 0 |
| D | 0 | 76 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 6 | 0 |
| B | 0 | 6 | 0 |
| C | 0 | 6 | 0 |
| D | 0 | 6 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 3657 | 149 | 4.074378% |
| B | 3655 | 159 | 4.350205% |
| C | 3656 | 105 | 2.871991% |
| D | 3656 | 132 | 3.610503% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 4270 | 3666 | 0 | 0 | 0.00% | 0.00% |  |
| B | 4270 | 3666 | 2 | 2 | 0.05% | 0.05% |  |
| C | 4270 | 3666 | 0 | 0 | 0.00% | 0.00% |  |
| D | 4270 | 3666 | 16 | 16 | 0.37% | 0.44% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 1 | 162 | 7363 | 71.78 | 462 | 451 | 96.3 |
| A | 0 | 226 | 4252 | 39.47 | 462 | 451 | 96.3 |
| A | 12 | 194 | 3691 | 33.65 | 462 | 451 | 96.3 |
| B | 0 | 219 | 30272 | 328.73 | 464 | 451 | 90.7 |
| B | 0 | 214 | 26820 | 290.67 | 464 | 451 | 90.7 |
| B | 0 | 187 | 26047 | 282.15 | 464 | 451 | 90.7 |
| C | 9 | 68 | 130309 | 1226.94 | 453 | 457 | 105.8 |
| C | 13 | 61 | 3446 | 28.24 | 453 | 457 | 105.8 |
| C | 14 | 67 | 1320 | 8.15 | 453 | 457 | 105.8 |
| D | 8 | 195 | 449720 | 4097.22 | 445 | 432 | 109.7 |
| D | 1 | 52 | 116413 | 1057.67 | 445 | 432 | 109.7 |
| D | 7 | 46 | 115995 | 1053.86 | 445 | 432 | 109.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
