| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A03_029T01_9000001384_09710cztM0_level2.evt | modeM0/AS1A03_029T01_9000001384_09710cztM0_level2_quad_clean.evt |
| Size (bytes) | 474,451,200 | 78,134,400 |
| Size | 452.5 MB | 74.5 MB |
| Events in quadrant A | 3,039,630 | 482,589 |
| Events in quadrant B | 3,228,262 | 496,979 |
| Events in quadrant C | 3,007,806 | 488,241 |
| Events in quadrant D | 4,662,867 | 455,845 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13055 | 3 |
| B | 0 | 13454 | 2 |
| C | 0 | 12991 | 2 |
| D | 0 | 18273 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13 | 0 |
| B | 0 | 13 | 0 |
| C | 0 | 13 | 0 |
| D | 0 | 14 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 128 | 0 |
| B | 0 | 128 | 0 |
| C | 0 | 128 | 0 |
| D | 0 | 128 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6341 | 39 | 0.615045% |
| B | 6341 | 30 | 0.473111% |
| C | 6341 | 19 | 0.299637% |
| D | 6341 | 112 | 1.766283% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7576 | 6342 | 5 | 5 | 0.07% | 0.08% |  |
| B | 7576 | 6342 | 3 | 3 | 0.04% | 0.05% |  |
| C | 7576 | 6342 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7576 | 6341 | 65 | 65 | 0.86% | 1.03% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 174 | 36504 | 226.26 | 779 | 764 | 158.0 |
| A | 0 | 226 | 7121 | 40.24 | 779 | 764 | 158.0 |
| A | 12 | 194 | 6437 | 35.91 | 779 | 764 | 158.0 |
| B | 0 | 214 | 45537 | 302.17 | 791 | 774 | 148.1 |
| B | 0 | 85 | 32223 | 212.29 | 791 | 774 | 148.1 |
| B | 0 | 229 | 22032 | 143.5 | 791 | 774 | 148.1 |
| C | 13 | 61 | 5837 | 28.63 | 768 | 775 | 176.8 |
| C | 14 | 234 | 5744 | 28.11 | 768 | 775 | 176.8 |
| C | 3 | 254 | 2644 | 10.57 | 768 | 775 | 176.8 |
| D | 1 | 52 | 1609013 | 8777.51 | 746 | 726 | 183.2 |
| D | 12 | 233 | 137661 | 747.35 | 746 | 726 | 183.2 |
| D | 2 | 152 | 23841 | 126.15 | 746 | 726 | 183.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
