| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G05_218T01_9000001394_09794cztM0_level2.evt | modeM0/AS1G05_218T01_9000001394_09794cztM0_level2_quad_clean.evt |
| Size (bytes) | 1,948,472,640 | 364,181,760 |
| Size | 1.8 GB | 347.3 MB |
| Events in quadrant A | 12,913,795 | 2,305,144 |
| Events in quadrant B | 13,323,414 | 2,339,738 |
| Events in quadrant C | 12,672,279 | 2,285,047 |
| Events in quadrant D | 18,197,605 | 2,164,525 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 572 | 0 |
| B | 0 | 572 | 0 |
| C | 0 | 572 | 0 |
| D | 0 | 572 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 57862 | 31 |
| B | 0 | 58685 | 23 |
| C | 0 | 57480 | 32 |
| D | 0 | 73660 | 61 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 38 | 0 |
| B | 0 | 38 | 0 |
| C | 0 | 38 | 0 |
| D | 0 | 38 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 28164 | 250 | 0.887658% |
| B | 28168 | 289 | 1.025987% |
| C | 28163 | 182 | 0.646238% |
| D | 28165 | 1173 | 4.164743% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 31930 | 28180 | 60 | 60 | 0.19% | 0.21% |  |
| B | 31930 | 28180 | 13 | 13 | 0.04% | 0.05% |  |
| C | 31930 | 28180 | 14 | 14 | 0.04% | 0.05% |  |
| D | 31930 | 28180 | 886 | 886 | 2.77% | 3.14% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 12 | 210 | 227341 | 336.58 | 3293 | 3224 | 665.9 |
| A | 0 | 226 | 30113 | 40.38 | 3293 | 3224 | 665.9 |
| A | 12 | 194 | 27213 | 36.03 | 3293 | 3224 | 665.9 |
| B | 4 | 239 | 168421 | 262.43 | 3310 | 3233 | 629.5 |
| B | 0 | 214 | 106050 | 163.34 | 3310 | 3233 | 629.5 |
| B | 12 | 111 | 71622 | 108.65 | 3310 | 3233 | 629.5 |
| C | 14 | 234 | 83756 | 108.81 | 3211 | 3224 | 740.1 |
| C | 5 | 128 | 27061 | 32.21 | 3211 | 3224 | 740.1 |
| C | 13 | 61 | 23705 | 27.67 | 3211 | 3224 | 740.1 |
| D | 1 | 52 | 3080189 | 3937.67 | 3145 | 3068 | 781.5 |
| D | 2 | 152 | 990115 | 1263.09 | 3145 | 3068 | 781.5 |
| D | 12 | 233 | 972961 | 1241.13 | 3145 | 3068 | 781.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
