| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G07_020T01_9000001398_09829cztM0_level2.evt | modeM0/AS1G07_020T01_9000001398_09829cztM0_level2_quad_clean.evt |
| Size (bytes) | 460,926,720 | 70,231,680 |
| Size | 439.6 MB | 67.0 MB |
| Events in quadrant A | 3,066,957 | 418,839 |
| Events in quadrant B | 3,269,618 | 432,077 |
| Events in quadrant C | 3,054,815 | 425,797 |
| Events in quadrant D | 4,123,401 | 393,618 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13356 | 1 |
| B | 0 | 13821 | 0 |
| C | 0 | 13332 | 0 |
| D | 0 | 16611 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 130 | 0 |
| B | 0 | 130 | 0 |
| C | 0 | 130 | 0 |
| D | 0 | 130 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13 | 0 |
| B | 0 | 13 | 0 |
| C | 0 | 13 | 0 |
| D | 0 | 13 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6549 | 27 | 0.412277% |
| B | 6549 | 53 | 0.809284% |
| C | 6549 | 25 | 0.381738% |
| D | 6549 | 221 | 3.374561% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7764 | 6550 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7764 | 6550 | 11 | 11 | 0.14% | 0.17% |  |
| C | 7764 | 6550 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7764 | 6550 | 157 | 157 | 2.02% | 2.40% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 3 | 1 | 9213 | 52.74 | 793 | 777 | 160.0 |
| A | 0 | 226 | 7301 | 40.78 | 793 | 777 | 160.0 |
| A | 12 | 194 | 6472 | 35.6 | 793 | 777 | 160.0 |
| B | 0 | 214 | 61802 | 400.56 | 806 | 787 | 152.3 |
| B | 0 | 230 | 28184 | 179.86 | 806 | 787 | 152.3 |
| B | 0 | 229 | 21125 | 133.52 | 806 | 787 | 152.3 |
| C | 13 | 61 | 5763 | 27.53 | 781 | 786 | 180.8 |
| C | 5 | 128 | 3065 | 12.61 | 781 | 786 | 180.8 |
| C | 14 | 67 | 2865 | 11.5 | 781 | 786 | 180.8 |
| D | 2 | 152 | 332386 | 1813.33 | 760 | 742 | 182.9 |
| D | 1 | 52 | 289209 | 1577.25 | 760 | 742 | 182.9 |
| D | 7 | 46 | 210635 | 1147.63 | 760 | 742 | 182.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
