| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A03_134T01_9000001400_09846cztM0_level2.evt | modeM0/AS1A03_134T01_9000001400_09846cztM0_level2_quad_clean.evt |
| Size (bytes) | 602,277,120 | 91,869,120 |
| Size | 574.4 MB | 87.6 MB |
| Events in quadrant A | 3,712,892 | 565,039 |
| Events in quadrant B | 3,829,811 | 573,920 |
| Events in quadrant C | 3,675,106 | 571,773 |
| Events in quadrant D | 6,491,226 | 526,852 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16686 | 159 |
| B | 0 | 16881 | 155 |
| C | 0 | 16702 | 177 |
| D | 0 | 25171 | 505 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 160 | 2 |
| B | 0 | 160 | 0 |
| C | 0 | 160 | 2 |
| D | 0 | 160 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 7 | 0 |
| B | 0 | 7 | 0 |
| C | 0 | 7 | 1 |
| D | 0 | 7 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7834 | 470 | 5.999489% |
| B | 7837 | 491 | 6.265152% |
| C | 7822 | 366 | 4.679110% |
| D | 7784 | 773 | 9.930627% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 8594 | 7904 | 2 | 2 | 0.02% | 0.03% |  |
| B | 8594 | 7903 | 11 | 11 | 0.13% | 0.14% |  |
| C | 8594 | 7905 | 0 | 0 | 0.00% | 0.00% |  |
| D | 8594 | 7890 | 296 | 296 | 3.44% | 3.75% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 239 | 25730 | 124.85 | 956 | 933 | 198.6 |
| A | 0 | 226 | 8697 | 39.09 | 956 | 933 | 198.6 |
| A | 12 | 194 | 7468 | 32.9 | 956 | 933 | 198.6 |
| B | 4 | 81 | 73145 | 386.82 | 956 | 929 | 186.7 |
| B | 12 | 111 | 22131 | 113.57 | 956 | 929 | 186.7 |
| B | 11 | 111 | 17820 | 90.47 | 956 | 929 | 186.7 |
| C | 14 | 67 | 11660 | 49.49 | 933 | 934 | 216.7 |
| C | 14 | 234 | 10295 | 43.19 | 933 | 934 | 216.7 |
| C | 13 | 61 | 7153 | 28.7 | 933 | 934 | 216.7 |
| D | 1 | 52 | 2689844 | 11719.03 | 900 | 876 | 229.5 |
| D | 2 | 16 | 260993 | 1133.64 | 900 | 876 | 229.5 |
| D | 2 | 234 | 29432 | 124.45 | 900 | 876 | 229.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
