| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1C02_028T02_9000001428_09999cztM0_level2.evt | modeM0/AS1C02_028T02_9000001428_09999cztM0_level2_quad_clean.evt |
| Size (bytes) | 1,069,436,160 | 179,205,120 |
| Size | 1019.9 MB | 170.9 MB |
| Events in quadrant A | 7,306,507 | 1,088,970 |
| Events in quadrant B | 7,853,985 | 1,104,485 |
| Events in quadrant C | 7,022,245 | 1,087,610 |
| Events in quadrant D | 9,132,394 | 1,052,520 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 320 | 0 |
| B | 0 | 320 | 0 |
| C | 0 | 320 | 2 |
| D | 0 | 320 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 32554 | 9 |
| B | 0 | 33974 | 16 |
| C | 0 | 32366 | 22 |
| D | 0 | 37708 | 14 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 5 | 0 |
| B | 0 | 5 | 0 |
| C | 0 | 5 | 0 |
| D | 0 | 5 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 15855 | 377 | 2.377799% |
| B | 15852 | 413 | 2.605349% |
| C | 15849 | 298 | 1.880245% |
| D | 15853 | 539 | 3.399987% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 16318 | 15858 | 4 | 4 | 0.02% | 0.03% |  |
| B | 16318 | 15858 | 36 | 36 | 0.22% | 0.23% |  |
| C | 16318 | 15857 | 1 | 1 | 0.01% | 0.01% |  |
| D | 16318 | 15858 | 199 | 199 | 1.22% | 1.25% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 8 | 15 | 206235 | 545.48 | 1828 | 1783 | 374.8 |
| A | 15 | 174 | 57890 | 149.69 | 1828 | 1783 | 374.8 |
| A | 0 | 226 | 16717 | 39.84 | 1828 | 1783 | 374.8 |
| B | 4 | 239 | 187840 | 528.28 | 1829 | 1780 | 352.2 |
| B | 4 | 81 | 171968 | 483.21 | 1829 | 1780 | 352.2 |
| B | 0 | 214 | 142967 | 400.87 | 1829 | 1780 | 352.2 |
| C | 8 | 128 | 23195 | 51.52 | 1785 | 1793 | 415.4 |
| C | 13 | 61 | 13272 | 27.63 | 1785 | 1793 | 415.4 |
| C | 8 | 112 | 12680 | 26.21 | 1785 | 1793 | 415.4 |
| D | 1 | 52 | 902400 | 2006.2 | 1773 | 1724 | 448.9 |
| D | 2 | 16 | 615635 | 1367.45 | 1773 | 1724 | 448.9 |
| D | 8 | 195 | 384901 | 853.5 | 1773 | 1724 | 448.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
