| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A03_084T01_9000001440_10059cztM0_level2.evt | modeM0/AS1A03_084T01_9000001440_10059cztM0_level2_quad_clean.evt |
| Size (bytes) | 500,754,240 | 95,258,880 |
| Size | 477.6 MB | 90.8 MB |
| Events in quadrant A | 3,290,561 | 627,598 |
| Events in quadrant B | 3,368,479 | 633,366 |
| Events in quadrant C | 3,007,988 | 612,344 |
| Events in quadrant D | 5,066,473 | 567,264 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14054 | 3 |
| B | 0 | 14163 | 2 |
| C | 0 | 13217 | 2 |
| D | 0 | 19454 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 130 | 0 |
| B | 0 | 130 | 0 |
| C | 0 | 130 | 0 |
| D | 0 | 130 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16 | 0 |
| B | 0 | 16 | 0 |
| C | 0 | 16 | 0 |
| D | 0 | 17 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6364 | 72 | 1.131364% |
| B | 6364 | 66 | 1.037084% |
| C | 6364 | 28 | 0.439975% |
| D | 6364 | 287 | 4.509742% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7684 | 6365 | 3 | 3 | 0.04% | 0.05% |  |
| B | 7684 | 6365 | 0 | 0 | 0.00% | 0.00% |  |
| C | 7684 | 6365 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7684 | 6364 | 257 | 257 | 3.34% | 4.04% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 8 | 15 | 139053 | 842.93 | 805 | 788 | 164.0 |
| A | 15 | 174 | 29618 | 175.76 | 805 | 788 | 164.0 |
| A | 15 | 239 | 22981 | 135.3 | 805 | 788 | 164.0 |
| B | 4 | 81 | 89515 | 583.97 | 802 | 784 | 151.9 |
| B | 4 | 239 | 32189 | 206.69 | 802 | 784 | 151.9 |
| B | 0 | 214 | 27538 | 176.08 | 802 | 784 | 151.9 |
| C | 14 | 67 | 14101 | 74.76 | 765 | 767 | 178.4 |
| C | 14 | 234 | 9370 | 48.24 | 765 | 767 | 178.4 |
| C | 13 | 61 | 5798 | 28.21 | 765 | 767 | 178.4 |
| D | 2 | 16 | 1152463 | 5618.26 | 751 | 736 | 205.0 |
| D | 1 | 52 | 651763 | 3175.79 | 751 | 736 | 205.0 |
| D | 8 | 195 | 166640 | 809.3 | 751 | 736 | 205.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
