| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A03_116T01_9000001460_10140cztM0_level2.evt | modeM0/AS1A03_116T01_9000001460_10140cztM0_level2_quad_clean.evt |
| Size (bytes) | 1,577,998,080 | 221,466,240 |
| Size | 1.5 GB | 211.2 MB |
| Events in quadrant A | 8,773,574 | 1,394,788 |
| Events in quadrant B | 9,940,982 | 1,398,308 |
| Events in quadrant C | 8,430,114 | 1,393,149 |
| Events in quadrant D | 19,363,308 | 1,211,606 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 25 | 0 |
| B | 0 | 25 | 0 |
| C | 0 | 25 | 0 |
| D | 0 | 25 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 386 | 0 |
| B | 0 | 386 | 0 |
| C | 0 | 386 | 0 |
| D | 0 | 386 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 39108 | 5 |
| B | 0 | 42097 | 4 |
| C | 0 | 38644 | 4 |
| D | 0 | 70393 | 4 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 19001 | 153 | 0.805221% |
| B | 19001 | 249 | 1.310457% |
| C | 19001 | 123 | 0.647334% |
| D | 19001 | 2981 | 15.688648% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 21426 | 19005 | 12 | 12 | 0.06% | 0.06% |  |
| B | 21426 | 19003 | 46 | 46 | 0.21% | 0.24% |  |
| C | 21426 | 19005 | 1 | 1 | 0.00% | 0.01% |  |
| D | 21426 | 19004 | 2484 | 2484 | 11.59% | 13.07% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 223 | 60149 | 128.4 | 2222 | 2174 | 451.5 |
| A | 8 | 5 | 47474 | 100.33 | 2222 | 2174 | 451.5 |
| A | 15 | 174 | 40617 | 85.14 | 2222 | 2174 | 451.5 |
| B | 4 | 81 | 501764 | 1170.78 | 2232 | 2174 | 426.7 |
| B | 0 | 189 | 436967 | 1018.93 | 2232 | 2174 | 426.7 |
| B | 0 | 214 | 120873 | 278.17 | 2232 | 2174 | 426.7 |
| C | 14 | 67 | 20191 | 36.04 | 2155 | 2165 | 500.1 |
| C | 13 | 61 | 16069 | 27.8 | 2155 | 2165 | 500.1 |
| C | 14 | 234 | 10259 | 16.18 | 2155 | 2165 | 500.1 |
| D | 4 | 95 | 8045937 | 16282.86 | 2004 | 1949 | 494.0 |
| D | 8 | 195 | 1312462 | 2652.78 | 2004 | 1949 | 494.0 |
| D | 2 | 16 | 1065179 | 2152.22 | 2004 | 1949 | 494.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
