| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A03_133T01_9000001464_10177cztM0_level2.evt | modeM0/AS1A03_133T01_9000001464_10177cztM0_level2_quad_clean.evt |
| Size (bytes) | 448,372,800 | 88,032,960 |
| Size | 427.6 MB | 84.0 MB |
| Events in quadrant A | 3,018,100 | 567,216 |
| Events in quadrant B | 3,162,998 | 567,963 |
| Events in quadrant C | 2,849,753 | 560,834 |
| Events in quadrant D | 4,119,269 | 529,388 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 128 | 0 |
| B | 0 | 128 | 0 |
| C | 0 | 128 | 0 |
| D | 0 | 128 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13167 | 2 |
| B | 0 | 13480 | 1 |
| C | 0 | 13020 | 1 |
| D | 0 | 16304 | 1 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 10 | 0 |
| B | 0 | 10 | 0 |
| C | 0 | 10 | 0 |
| D | 0 | 10 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6313 | 63 | 0.997941% |
| B | 6313 | 78 | 1.235546% |
| C | 6313 | 33 | 0.522731% |
| D | 6313 | 71 | 1.124663% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7323 | 6314 | 7 | 7 | 0.10% | 0.11% |  |
| B | 7323 | 6314 | 2 | 2 | 0.03% | 0.03% |  |
| C | 7323 | 6314 | 2 | 2 | 0.03% | 0.03% |  |
| D | 7323 | 6313 | 29 | 29 | 0.40% | 0.46% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 8 | 15 | 61312 | 389.95 | 756 | 740 | 155.3 |
| A | 15 | 174 | 33220 | 209.1 | 756 | 740 | 155.3 |
| A | 3 | 1 | 9855 | 58.68 | 756 | 740 | 155.3 |
| B | 0 | 219 | 83103 | 571.25 | 755 | 739 | 144.2 |
| B | 4 | 239 | 48268 | 329.64 | 755 | 739 | 144.2 |
| B | 5 | 255 | 32095 | 217.47 | 755 | 739 | 144.2 |
| C | 4 | 254 | 20182 | 116.28 | 721 | 726 | 167.3 |
| C | 14 | 67 | 10770 | 60.03 | 721 | 726 | 167.3 |
| C | 13 | 61 | 5555 | 28.86 | 721 | 726 | 167.3 |
| D | 8 | 195 | 542966 | 3154.74 | 718 | 698 | 171.9 |
| D | 2 | 16 | 355199 | 2062.37 | 718 | 698 | 171.9 |
| D | 1 | 52 | 166571 | 965.0 | 718 | 698 | 171.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
