| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A03_050T01_9000001468_10195cztM0_level2.evt | modeM0/AS1A03_050T01_9000001468_10195cztM0_level2_quad_clean.evt |
| Size (bytes) | 580,475,520 | 131,866,560 |
| Size | 553.6 MB | 125.8 MB |
| Events in quadrant A | 3,758,275 | 858,821 |
| Events in quadrant B | 4,088,072 | 868,577 |
| Events in quadrant C | 3,568,675 | 874,883 |
| Events in quadrant D | 5,614,743 | 828,199 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16967 | 4 |
| B | 0 | 17587 | 3 |
| C | 0 | 16543 | 3 |
| D | 0 | 22128 | 3 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 5 | 0 |
| B | 0 | 5 | 0 |
| C | 0 | 5 | 0 |
| D | 0 | 5 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 168 | 0 |
| B | 0 | 168 | 0 |
| C | 0 | 168 | 0 |
| D | 0 | 168 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 8101 | 107 | 1.320825% |
| B | 8101 | 163 | 2.012097% |
| C | 8101 | 52 | 0.641896% |
| D | 8101 | 184 | 2.271325% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 8686 | 8105 | 11 | 11 | 0.13% | 0.14% |  |
| B | 8686 | 8105 | 26 | 26 | 0.30% | 0.32% |  |
| C | 8686 | 8105 | 1 | 1 | 0.01% | 0.01% |  |
| D | 8686 | 8105 | 72 | 72 | 0.83% | 0.89% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 223 | 72899 | 377.0 | 931 | 910 | 191.0 |
| A | 15 | 174 | 51200 | 263.36 | 931 | 910 | 191.0 |
| A | 15 | 239 | 23618 | 118.92 | 931 | 910 | 191.0 |
| B | 11 | 51 | 167896 | 926.5 | 936 | 914 | 180.2 |
| B | 5 | 255 | 124596 | 686.25 | 936 | 914 | 180.2 |
| B | 4 | 239 | 55683 | 303.89 | 936 | 914 | 180.2 |
| C | 14 | 67 | 20854 | 95.47 | 905 | 906 | 208.9 |
| C | 13 | 61 | 6811 | 28.26 | 905 | 906 | 208.9 |
| C | 8 | 128 | 4935 | 19.28 | 905 | 906 | 208.9 |
| D | 8 | 195 | 746975 | 3521.58 | 894 | 868 | 211.9 |
| D | 2 | 16 | 594191 | 2800.45 | 894 | 868 | 211.9 |
| D | 1 | 52 | 310806 | 1462.89 | 894 | 868 | 211.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
