| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A03_050T01_9000001468_10198cztM0_level2.evt | modeM0/AS1A03_050T01_9000001468_10198cztM0_level2_quad_clean.evt |
| Size (bytes) | 1,348,807,680 | 286,303,680 |
| Size | 1.3 GB | 273.0 MB |
| Events in quadrant A | 8,935,967 | 1,839,231 |
| Events in quadrant B | 9,396,852 | 1,864,010 |
| Events in quadrant C | 8,387,502 | 1,877,862 |
| Events in quadrant D | 12,837,926 | 1,775,162 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 40092 | 5 |
| B | 0 | 40637 | 4 |
| C | 0 | 38710 | 4 |
| D | 0 | 50185 | 4 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 25 | 0 |
| B | 0 | 25 | 0 |
| C | 0 | 25 | 0 |
| D | 0 | 25 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 388 | 0 |
| B | 0 | 388 | 0 |
| C | 0 | 388 | 0 |
| D | 0 | 388 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 19101 | 252 | 1.319303% |
| B | 19101 | 239 | 1.251243% |
| C | 19101 | 98 | 0.513062% |
| D | 19101 | 574 | 3.005078% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 21546 | 19104 | 90 | 90 | 0.42% | 0.47% |  |
| B | 21546 | 19104 | 44 | 44 | 0.20% | 0.23% |  |
| C | 21546 | 19104 | 1 | 1 | 0.00% | 0.01% |  |
| D | 21546 | 19104 | 416 | 416 | 1.93% | 2.18% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 223 | 243997 | 552.1 | 2177 | 2126 | 438.1 |
| A | 15 | 174 | 117068 | 262.37 | 2177 | 2126 | 438.1 |
| A | 15 | 239 | 113915 | 255.17 | 2177 | 2126 | 438.1 |
| B | 5 | 255 | 256674 | 608.23 | 2199 | 2141 | 418.5 |
| B | 4 | 239 | 155756 | 367.08 | 2199 | 2141 | 418.5 |
| B | 11 | 51 | 132654 | 311.87 | 2199 | 2141 | 418.5 |
| C | 14 | 67 | 32313 | 61.52 | 2137 | 2149 | 490.3 |
| C | 13 | 61 | 16034 | 28.32 | 2137 | 2149 | 490.3 |
| C | 8 | 128 | 12547 | 21.2 | 2137 | 2149 | 490.3 |
| D | 8 | 195 | 1437111 | 2880.24 | 2100 | 2039 | 498.2 |
| D | 1 | 52 | 1312675 | 2630.49 | 2100 | 2039 | 498.2 |
| D | 1 | 20 | 706115 | 1413.1 | 2100 | 2039 | 498.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
