| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G07_027T01_9000001470_10208cztM0_level2.evt | modeM0/AS1G07_027T01_9000001470_10208cztM0_level2_quad_clean.evt |
| Size (bytes) | 553,544,640 | 107,064,000 |
| Size | 527.9 MB | 102.1 MB |
| Events in quadrant A | 3,633,207 | 693,074 |
| Events in quadrant B | 3,951,294 | 693,312 |
| Events in quadrant C | 3,547,830 | 682,743 |
| Events in quadrant D | 5,120,970 | 649,232 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16002 | 3 |
| B | 0 | 16746 | 2 |
| C | 0 | 15706 | 2 |
| D | 0 | 20449 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 152 | 0 |
| B | 0 | 152 | 0 |
| C | 0 | 152 | 0 |
| D | 0 | 152 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 2 | 0 |
| B | 0 | 2 | 0 |
| C | 0 | 2 | 0 |
| D | 0 | 3 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7532 | 113 | 1.500266% |
| B | 7532 | 220 | 2.920871% |
| C | 7532 | 70 | 0.929368% |
| D | 7532 | 140 | 1.858736% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7727 | 7535 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7727 | 7535 | 46 | 46 | 0.60% | 0.61% |  |
| C | 7727 | 7535 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7727 | 7535 | 22 | 22 | 0.28% | 0.29% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 223 | 43615 | 228.25 | 921 | 900 | 187.1 |
| A | 8 | 15 | 36921 | 192.48 | 921 | 900 | 187.1 |
| A | 15 | 239 | 11491 | 56.59 | 921 | 900 | 187.1 |
| B | 5 | 255 | 124247 | 697.31 | 916 | 893 | 176.9 |
| B | 11 | 51 | 106063 | 594.52 | 916 | 893 | 176.9 |
| B | 4 | 239 | 69511 | 387.89 | 916 | 893 | 176.9 |
| C | 0 | 207 | 27672 | 127.39 | 894 | 898 | 210.2 |
| C | 8 | 128 | 11198 | 49.01 | 894 | 898 | 210.2 |
| C | 14 | 67 | 10484 | 45.61 | 894 | 898 | 210.2 |
| D | 8 | 195 | 766000 | 3340.52 | 883 | 865 | 229.0 |
| D | 1 | 52 | 589762 | 2571.08 | 883 | 865 | 229.0 |
| D | 2 | 16 | 138761 | 602.04 | 883 | 865 | 229.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
