| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A03_095T03_9000001474_10242cztM0_level2.evt | modeM0/AS1A03_095T03_9000001474_10242cztM0_level2_quad_clean.evt |
| Size (bytes) | 161,991,360 | 21,522,240 |
| Size | 154.5 MB | 20.5 MB |
| Events in quadrant A | 1,154,779 | 122,476 |
| Events in quadrant B | 1,122,078 | 111,192 |
| Events in quadrant C | 1,160,883 | 125,773 |
| Events in quadrant D | 1,290,113 | 107,192 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 124 | 64 |
| B | 0 | 124 | 63 |
| C | 0 | 124 | 69 |
| D | 0 | 121 | 60 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11832 | 6412 |
| B | 0 | 13286 | 8252 |
| C | 0 | 12322 | 6878 |
| D | 0 | 14129 | 9068 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 4 | 0 |
| B | 0 | 4 | 0 |
| C | 0 | 4 | 0 |
| D | 0 | 5 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 2678 | 6 | 0.224048% |
| B | 2451 | 16 | 0.652795% |
| C | 2682 | 8 | 0.298285% |
| D | 2408 | 8 | 0.332226% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 3155 | 3088 | 0 | 0 | 0.00% | 0.00% |  |
| B | 3155 | 2926 | 1 | 1 | 0.03% | 0.03% |  |
| C | 3154 | 3092 | 0 | 0 | 0.00% | 0.00% |  |
| D | 3155 | 2747 | 1 | 1 | 0.03% | 0.04% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 226 | 2655 | 38.06 | 298 | 292 | 62.1 |
| A | 12 | 194 | 2411 | 34.13 | 298 | 292 | 62.1 |
| A | 4 | 2 | 1785 | 24.04 | 298 | 292 | 62.1 |
| B | 0 | 214 | 10707 | 191.34 | 277 | 271 | 54.5 |
| B | 4 | 239 | 10441 | 186.46 | 277 | 271 | 54.5 |
| B | 10 | 247 | 10084 | 179.92 | 277 | 271 | 54.5 |
| C | 14 | 67 | 4332 | 56.82 | 296 | 297 | 71.0 |
| C | 13 | 61 | 2141 | 25.97 | 296 | 297 | 71.0 |
| C | 12 | 4 | 1376 | 15.2 | 296 | 297 | 71.0 |
| D | 8 | 195 | 192613 | 3017.88 | 258 | 250 | 63.7 |
| D | 1 | 52 | 85048 | 1330.35 | 258 | 250 | 63.7 |
| D | 2 | 14 | 16392 | 253.24 | 258 | 250 | 63.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
