| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A03_052T01_9000001480_10265cztM0_level2.evt | modeM0/AS1A03_052T01_9000001480_10265cztM0_level2_quad_clean.evt |
| Size (bytes) | 466,729,920 | 88,986,240 |
| Size | 445.1 MB | 84.9 MB |
| Events in quadrant A | 3,214,610 | 567,702 |
| Events in quadrant B | 3,663,848 | 568,994 |
| Events in quadrant C | 3,039,472 | 554,940 |
| Events in quadrant D | 3,756,815 | 531,217 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 138 | 0 |
| B | 0 | 138 | 0 |
| C | 0 | 138 | 0 |
| D | 0 | 138 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14035 | 2 |
| B | 0 | 15200 | 1 |
| C | 0 | 13885 | 1 |
| D | 0 | 15514 | 1 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 6 | 0 |
| B | 0 | 6 | 0 |
| C | 0 | 6 | 0 |
| D | 0 | 6 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6770 | 68 | 1.004431% |
| B | 6770 | 121 | 1.787297% |
| C | 6770 | 25 | 0.369276% |
| D | 6770 | 80 | 1.181684% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7350 | 6771 | 1 | 1 | 0.01% | 0.01% |  |
| B | 7350 | 6771 | 37 | 37 | 0.50% | 0.55% |  |
| C | 7350 | 6771 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7350 | 6771 | 54 | 54 | 0.73% | 0.80% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 8 | 15 | 53807 | 319.57 | 814 | 796 | 165.9 |
| A | 8 | 5 | 12805 | 72.39 | 814 | 796 | 165.9 |
| A | 15 | 174 | 11302 | 63.33 | 814 | 796 | 165.9 |
| B | 4 | 239 | 245026 | 1552.91 | 810 | 791 | 157.3 |
| B | 11 | 51 | 123403 | 779.6 | 810 | 791 | 157.3 |
| B | 0 | 214 | 82261 | 518.01 | 810 | 791 | 157.3 |
| C | 13 | 61 | 5890 | 28.18 | 778 | 782 | 181.3 |
| C | 14 | 67 | 5845 | 27.93 | 778 | 782 | 181.3 |
| C | 3 | 202 | 1927 | 6.32 | 778 | 782 | 181.3 |
| D | 1 | 52 | 209408 | 1117.92 | 778 | 757 | 186.6 |
| D | 8 | 195 | 185583 | 990.27 | 778 | 757 | 186.6 |
| D | 13 | 104 | 112577 | 599.11 | 778 | 757 | 186.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
