| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A03_124T01_9000001486_10319cztM0_level2.evt | modeM0/AS1A03_124T01_9000001486_10319cztM0_level2_quad_clean.evt |
| Size (bytes) | 485,153,280 | 68,880,960 |
| Size | 462.7 MB | 65.7 MB |
| Events in quadrant A | 3,691,935 | 414,040 |
| Events in quadrant B | 3,855,251 | 416,903 |
| Events in quadrant C | 3,259,660 | 408,064 |
| Events in quadrant D | 3,441,149 | 389,490 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14834 | 3 |
| B | 0 | 15439 | 2 |
| C | 0 | 13757 | 2 |
| D | 0 | 14327 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 26 | 0 |
| B | 0 | 26 | 0 |
| C | 0 | 26 | 0 |
| D | 0 | 26 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 134 | 0 |
| B | 0 | 134 | 0 |
| C | 0 | 134 | 0 |
| D | 0 | 134 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6556 | 161 | 2.455766% |
| B | 6556 | 238 | 3.630262% |
| C | 6556 | 79 | 1.205003% |
| D | 6556 | 82 | 1.250763% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 9131 | 6556 | 44 | 44 | 0.48% | 0.67% |  |
| B | 9131 | 6556 | 71 | 71 | 0.78% | 1.08% |  |
| C | 9131 | 6557 | 4 | 4 | 0.04% | 0.06% |  |
| D | 9131 | 6556 | 6 | 6 | 0.07% | 0.09% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 8 | 5 | 176578 | 1025.06 | 862 | 846 | 171.4 |
| A | 8 | 15 | 169371 | 983.02 | 862 | 846 | 171.4 |
| A | 3 | 1 | 28156 | 159.3 | 862 | 846 | 171.4 |
| B | 4 | 239 | 386150 | 2413.43 | 857 | 840 | 159.7 |
| B | 11 | 51 | 73878 | 457.48 | 857 | 840 | 159.7 |
| B | 0 | 214 | 34898 | 213.33 | 857 | 840 | 159.7 |
| C | 14 | 234 | 41982 | 218.19 | 825 | 830 | 188.6 |
| C | 13 | 61 | 6237 | 28.67 | 825 | 830 | 188.6 |
| C | 3 | 202 | 2007 | 6.24 | 825 | 830 | 188.6 |
| D | 8 | 195 | 160678 | 822.11 | 821 | 801 | 194.5 |
| D | 1 | 52 | 63308 | 321.42 | 821 | 801 | 194.5 |
| D | 13 | 104 | 27375 | 136.65 | 821 | 801 | 194.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
