| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A03_126T01_9000001512_10436cztM0_level2.evt | modeM0/AS1A03_126T01_9000001512_10436cztM0_level2_quad_clean.evt |
| Size (bytes) | 350,956,800 | 60,287,040 |
| Size | 334.7 MB | 57.5 MB |
| Events in quadrant A | 2,677,096 | 288,892 |
| Events in quadrant B | 2,364,234 | 383,984 |
| Events in quadrant C | 2,291,260 | 406,174 |
| Events in quadrant D | 2,992,311 | 433,413 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 238 | 131 |
| B | 0 | 238 | 131 |
| C | 0 | 238 | 141 |
| D | 0 | 229 | 120 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 41202 | 30976 |
| B | 0 | 29577 | 19888 |
| C | 0 | 24389 | 14612 |
| D | 0 | 26330 | 14227 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 23 | 10 |
| B | 0 | 26 | 13 |
| C | 0 | 26 | 13 |
| D | 0 | 21 | 8 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 3319 | 64 | 1.928292% |
| B | 4263 | 34 | 0.797560% |
| C | 4741 | 7 | 0.147648% |
| D | 5353 | 23 | 0.429666% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7149 | 4347 | 3 | 3 | 0.04% | 0.07% |  |
| B | 7150 | 5185 | 2 | 2 | 0.03% | 0.04% |  |
| C | 7150 | 5588 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7151 | 5724 | 3 | 3 | 0.04% | 0.05% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 251 | 1026604 | 12312.32 | 404 | 395 | 83.3 |
| A | 3 | 80 | 74845 | 893.24 | 404 | 395 | 83.3 |
| A | 15 | 174 | 8901 | 102.05 | 404 | 395 | 83.3 |
| B | 4 | 239 | 282183 | 2884.5 | 518 | 506 | 97.7 |
| B | 11 | 51 | 25563 | 256.59 | 518 | 506 | 97.7 |
| B | 0 | 214 | 15452 | 153.05 | 518 | 506 | 97.7 |
| C | 14 | 234 | 50724 | 376.36 | 574 | 578 | 133.2 |
| C | 13 | 61 | 4119 | 26.58 | 574 | 578 | 133.2 |
| C | 14 | 67 | 3490 | 21.86 | 574 | 578 | 133.2 |
| D | 8 | 195 | 207196 | 1363.96 | 639 | 625 | 151.4 |
| D | 1 | 20 | 191062 | 1257.43 | 639 | 625 | 151.4 |
| D | 5 | 222 | 81568 | 534.45 | 639 | 625 | 151.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
