| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A03_126T01_9000001512_10476cztM0_level2.evt | modeM0/AS1A03_126T01_9000001512_10476cztM0_level2_quad_clean.evt |
| Size (bytes) | 460,010,880 | 92,030,400 |
| Size | 438.7 MB | 87.8 MB |
| Events in quadrant A | 3,111,481 | 591,079 |
| Events in quadrant B | 3,763,739 | 602,110 |
| Events in quadrant C | 2,879,054 | 596,064 |
| Events in quadrant D | 3,752,612 | 561,695 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 134 | 5 |
| B | 0 | 134 | 7 |
| C | 0 | 134 | 6 |
| D | 0 | 133 | 6 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13707 | 391 |
| B | 0 | 15755 | 414 |
| C | 0 | 13124 | 423 |
| D | 0 | 15769 | 414 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12 | 0 |
| B | 0 | 12 | 0 |
| C | 0 | 12 | 0 |
| D | 0 | 13 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6244 | 26 | 0.416400% |
| B | 6251 | 215 | 3.439450% |
| C | 6242 | 6 | 0.096123% |
| D | 6253 | 89 | 1.423317% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7424 | 6289 | 1 | 1 | 0.01% | 0.02% |  |
| B | 7424 | 6289 | 88 | 88 | 1.19% | 1.40% |  |
| C | 7424 | 6288 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7423 | 6286 | 49 | 49 | 0.66% | 0.78% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 3 | 80 | 92622 | 601.6 | 753 | 738 | 152.7 |
| A | 5 | 16 | 60717 | 392.7 | 753 | 738 | 152.7 |
| A | 8 | 5 | 27107 | 172.65 | 753 | 738 | 152.7 |
| B | 4 | 239 | 685050 | 4797.94 | 753 | 734 | 142.6 |
| B | 0 | 214 | 51344 | 354.84 | 753 | 734 | 142.6 |
| B | 0 | 187 | 38346 | 263.71 | 753 | 734 | 142.6 |
| C | 13 | 61 | 5267 | 26.34 | 737 | 740 | 171.9 |
| C | 14 | 67 | 2623 | 10.96 | 737 | 740 | 171.9 |
| C | 8 | 222 | 1924 | 6.89 | 737 | 740 | 171.9 |
| D | 1 | 20 | 342438 | 1967.89 | 724 | 705 | 173.7 |
| D | 8 | 195 | 199719 | 1146.03 | 724 | 705 | 173.7 |
| D | 13 | 122 | 122721 | 702.64 | 724 | 705 | 173.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
