| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G07_066T01_9000001510_10430cztM0_level2.evt | modeM0/AS1G07_066T01_9000001510_10430cztM0_level2_quad_clean.evt |
| Size (bytes) | 337,950,720 | 57,784,320 |
| Size | 322.3 MB | 55.1 MB |
| Events in quadrant A | 2,467,548 | 288,919 |
| Events in quadrant B | 2,301,910 | 369,001 |
| Events in quadrant C | 2,171,419 | 403,305 |
| Events in quadrant D | 2,990,464 | 375,690 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 286 | 181 |
| B | 0 | 285 | 182 |
| C | 0 | 285 | 190 |
| D | 0 | 280 | 177 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 29 | 15 |
| B | 0 | 32 | 16 |
| C | 0 | 32 | 16 |
| D | 0 | 31 | 15 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 44256 | 34659 |
| B | 0 | 34264 | 24570 |
| C | 0 | 27861 | 18004 |
| D | 0 | 35801 | 23825 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 3522 | 73 | 2.072686% |
| B | 4417 | 46 | 1.041431% |
| C | 4898 | 4 | 0.081666% |
| D | 4756 | 19 | 0.399495% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 8585 | 4778 | 14 | 14 | 0.16% | 0.29% |  |
| B | 8585 | 5697 | 3 | 3 | 0.03% | 0.05% |  |
| C | 8587 | 6208 | 0 | 0 | 0.00% | 0.00% |  |
| D | 8587 | 5873 | 1 | 1 | 0.01% | 0.02% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 251 | 807477 | 9590.63 | 402 | 392 | 84.2 |
| A | 3 | 80 | 100058 | 1184.34 | 402 | 392 | 84.2 |
| A | 15 | 174 | 4151 | 44.67 | 402 | 392 | 84.2 |
| B | 4 | 239 | 234857 | 2365.87 | 512 | 499 | 99.1 |
| B | 0 | 214 | 32278 | 320.81 | 512 | 499 | 99.1 |
| B | 11 | 51 | 20020 | 197.07 | 512 | 499 | 99.1 |
| C | 14 | 67 | 6166 | 43.55 | 554 | 556 | 128.8 |
| C | 13 | 61 | 4215 | 28.41 | 554 | 556 | 128.8 |
| C | 8 | 222 | 2621 | 16.03 | 554 | 556 | 128.8 |
| D | 8 | 195 | 436814 | 3431.31 | 527 | 512 | 127.2 |
| D | 1 | 20 | 191277 | 1500.28 | 527 | 512 | 127.2 |
| D | 1 | 255 | 181087 | 1420.14 | 527 | 512 | 127.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
