| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G07_057T01_9000001520_10496cztM0_level2.evt | modeM0/AS1G07_057T01_9000001520_10496cztM0_level2_quad_clean.evt |
| Size (bytes) | 444,807,360 | 59,466,240 |
| Size | 424.2 MB | 56.7 MB |
| Events in quadrant A | 2,607,788 | 359,876 |
| Events in quadrant B | 3,504,708 | 362,146 |
| Events in quadrant C | 2,552,261 | 363,947 |
| Events in quadrant D | 4,435,115 | 331,922 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 117 | 5 |
| B | 0 | 116 | 4 |
| C | 0 | 115 | 3 |
| D | 0 | 115 | 3 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 9 | 0 |
| B | 0 | 9 | 0 |
| C | 0 | 9 | 0 |
| D | 0 | 9 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11617 | 417 |
| B | 0 | 14353 | 438 |
| C | 0 | 11737 | 417 |
| D | 0 | 17301 | 501 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5468 | 76 | 1.389905% |
| B | 5466 | 335 | 6.128796% |
| C | 5465 | 39 | 0.713632% |
| D | 5458 | 434 | 7.951631% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 6365 | 5510 | 0 | 0 | 0.00% | 0.00% |  |
| B | 6360 | 5516 | 192 | 192 | 3.02% | 3.48% |  |
| C | 6356 | 5515 | 10 | 10 | 0.16% | 0.18% |  |
| D | 6365 | 5512 | 384 | 384 | 6.03% | 6.97% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 3 | 80 | 52236 | 386.37 | 656 | 643 | 133.5 |
| A | 15 | 239 | 10380 | 72.92 | 656 | 643 | 133.5 |
| A | 8 | 5 | 8239 | 56.89 | 656 | 643 | 133.5 |
| B | 4 | 239 | 839885 | 6709.32 | 646 | 629 | 125.1 |
| B | 0 | 214 | 56492 | 446.59 | 646 | 629 | 125.1 |
| B | 11 | 51 | 43077 | 339.34 | 646 | 629 | 125.1 |
| C | 14 | 234 | 81177 | 539.68 | 633 | 636 | 149.2 |
| C | 13 | 61 | 4666 | 27.0 | 633 | 636 | 149.2 |
| C | 14 | 67 | 1678 | 6.98 | 633 | 636 | 149.2 |
| D | 12 | 233 | 1259254 | 7728.86 | 608 | 594 | 162.9 |
| D | 2 | 16 | 243142 | 1489.38 | 608 | 594 | 162.9 |
| D | 1 | 20 | 232970 | 1426.92 | 608 | 594 | 162.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
